Functional electrical characteristics
Command board
Redundacy of command board
Percentage of load admitted
after rupture of a control board
Model
Power Module PM7
Maximum output power during
replacement mode Hot
swappable modules
Maximum output power in case of
failure of a module (Redundancy)
Power Module PM7
Characteristics
of Power Module PM7
Number of Display
Characteristics of Display
RS232 user port
RS232 maintenance port
Contact port
3 104 51
3 104 53 3 104 54
3 104 52
1 2
No
- 50% 66%
20 kVA 40 kVA 60 kVA
3 PM7
driven
3 PM7
by control
driven
board N.1
by control
board N.1
3 PM7
3 PM7
driven driven
by control
by control
board N.1
board N.2
3 PM7
driven
3 PM7
by control
driven
board N.2
by control
board N.3
- 50% 66%
0% (with
3 fhase
load)
50% 66%
66% (with
single
fhase load)
3 6
Nominale Power 6.7kVA
Active Power 5.4kW
Hot swappable electronics is permitted by dedicated procedure,
replacing a power module with the machine on after turning off,
via the relative control board, its corresponding 3-phase block
(3 or 6 power modules).
1 2
Independent displays each connected
NON Hot
Swappable
Display back light green background
Multicolor Status Indicator operation (green / yellow / red)
N.1 N.2
Rear side Rear side
N.1 N.2
Front side Front side
N.1 DB15 N.2 DB15
rear side rear side
Archimod®
3 104 55 3 104 56
3
Yes
(50÷75)% (60÷80)%
80 kVA 100 kVA
6 PM7 6 PM7
driven driven
by control by control
board N.1 board N.1
3 PM7 6 PM7
driven driven
by control by control
board N.2 board N.2
3 PM7 3 PM7
driven driven
by control by control
board N.3 board N.3
(50÷75)% (60÷80)%
75% 80%
9 12 15
3
Redundant.
with a separate command.
N.3
Rear side
N.3
Front side
N.3 DB15
rear side
3 104 57
66%
120 kVA
6 PM7
driven
by control
board N.1
6 PM7
driven
by control
board N.2
6 PM7
driven
by control
board N.3
66%
84%
18
(continue)
