7. Control panel
8 measurements on the input;
L1i229V
L2i228V
L3i230V
Batt.
C 50%
In carica
The keys on the front panel are used to gain access to the UPS menus
INDICATION
Press the ENTER key on the main frame to gain access to the main menu which contains the following options:
- UPS STATUS: it allows checking of the UPS's functional status in real time;
- UPS SETTINGS: it allows configuration of all the UPS functions;
- POWER MODULES: it allows analysing of the status of each single power module in real time;
- EVENTS: it allows the visual display and/or deletion of stored events in the UPS log;
- TOOLS: it allows a series of functional tests to be run on the UPS.
- LOG OUT: it allows the session to be terminated by entering a password:
By selecting one of the above listed items again with "ENTER", you gain access to the relative submenu. The following
table summarises them all.
52
®
MAIN PAGE
ARCHIMOD
3.4A 408W
2.9A 162W
2.6A 228W
9 bypass line voltages;
ARCHIMOD
L1b-L2b 401V
L2b-L3b 402V
L3b-L1b 400V
10 Battery status;
ARCHIMOD
288V -0,3A
λ
R 12h T 24h
- mant.
DATA DISPLAYED
1st line: UPS operating status;
2nd line: Phase L1 in input: Voltage, current and active power;
3rd line: Phase L2 in input: Voltage, current and active power;
4th line: Phase L3 in input: Voltage, current and active power.
1st line: UPS operating status;
2nd bypass line: line voltage between phases L1 and L2;
3rd bypass line: line voltage between phases L2 and L3;
4th bypass line: line voltage between phases L3 and L1.
1st line: UPS operating status;
2nd line: voltage, load current (negative value with ongoing load,
positive value when the batteries are powering the machine);
3rd line: capacity percentage of the batteries with respect to the
nominal, autonomy time left, total autonomy time;
4th line: battery status:
- Batt. on Standby: Batteries on stand-by
- Running down: Batteries running down
- Autonomy reserve: Autonomy reserve:
- End of autonomy: End of autonomy, UPS shutting down;
- Charging - f1: battery charging status (current limitation);
- Charging - f2: battery charging status (voltage limitation);
- Charging – maint.: Battery charge in maintenance;
- Batt. being tested Batteries being tested;
- Battery Equal.batteries being equalised;
- BATTERIES FAILED: batteries failed;
- Max. Battery time Maximum time when the battery is flat, UPS
shutting down;
