SIGNALLING EVENTS
MESSAGE
Shutting down due to end of autonomy
Shutting down due to incorrect three-phase
sequence
Batt.cal.interrupted
Maximum time on battery
Start-up error
Start-up authorised when there
are ongoing alarms
Startup authorised with a new config.
Shutting down due
to incorrect configuration
Power Module FW update
Big overload
Feeding from the output
Shutting down with H.V. buses loaded
Maintenance required
Check the batteries
Replace the batteries
MEANING
UPS shut down due to the end of autonomy.
UPS shut down due to an incorrect three-phase sequence in input.
Battery calibration interrupted by user
Maximum time on battery.
Error in starting up.
UPS start-up authorised in the presence of alarms.
UPS start-up authorised with a new configuration.
The number of Power Modules installed on the UPS has changed.
UPS shutting down due to an incorrect configuration.
The number of Power Modules detected by the UPS is incorrect
for the output configuration set.
The Power Module Firmware updated.
Big overload
Voltage present on the UPS output. Check connections.
The UPS did not shutdown correctly.
The UPS shutdown without discharging all the buses completely.
Have specialized personnel carry out the routine check on the UPS.
Have specialized personnel check the batteries.
Check battery status and replace them if necessary.
