HMS Netbiter EasyConnect User Manual page 14

Connections
2.3.4 Antenna Connector
The antenna connector is a standard female SMA screw connector. Optional external an‐
tennas are available from your supplier.
2.3.5 SIM Card
Netbiter SIM card
The Netbiter SIM cards supplied by HMS are pre‐configured and ready for use and have
PIN code security disabled as default.
Other SIM cards
To use any other SIM card, the following information is required:
• The phone number for the SIM card
• The Access Point Name (APN) to connect to
• User name and password (if required by the network operator)
!
SIM cards with active PIN codes cannot be used in Netbiter EC250. The PIN code
cannot be disabled in the gateway or in Netbiter Argos. To disable the PIN code, put
the SIM card in a mobile phone and follow the manufacturer's instructions.
Installing the SIM card
1. Push the yellow button next to the SIM card holder and remove the holder.
2. Place the SIM card in the holder and insert the holder into the unit as shown in the
figure. Observe the position of the cut‐off corner and the contact surfaces.
