Technical Specifications
11.3 Specifications EC250, EC310 & EC350
Netbiter EC250
Order codes NB1003
Ethernet 10/100 Mbit/s
Mobile communication Quad band GPRS Class 12
850/900/1800/1900 MHz
Alarms Email, SMS
Relay output N/A
(max 24V AC/DC, 1A)
Digital inputs 2, isolated max 24 VDC
Analog inputs N/A
Serial port #1 RS-232 up to 115.2 kbit/s
Serial port #2 RS-485 up to 115.2 kbit/s
Antenna connector SMA female
Protocols Modbus-RTU, ASCII, TCP
Connected devices 32
Baud rates 300–115200 baud
Wall mounting No
DIN rail mounting Yes
Dimensions (WxDxH) 90 x 70 x 58 mm
Operating temperature -30 to +65 °C
Storage temperature -40 to +85 °C
Housing class IP20
Power supply 9–24 VDC
Power consumption 3 W
Certifications CE
RoHS
UL
C US
FCC/IC (Pending)
PTCRB (Pending)
Netbiter EasyConnect Gateway User Manual
Netbiter EC310
NB1007
10/100 Mbit/s
N/A
Email, SMS
1
2, dry contact type
4 inputs, all supporting 0–10 V or 0–20 mA.
Current: 0–20 mA, R=3.3 %, A/D=0.1 mV+0.15 %
Voltage: 0–10 VDC, R=1.7 %, A/D=0.1 mV+0.15 %
Support for PT100 on AI1 and AI3. Sensor range -50 to +150 °C.
16-bit resolution.
RS-232 up to 115.2 kbit/s
RS-485 up to 115.2 kbit/s
N/A
Modbus-RTU, Modbus TCP. EtherNet/IP
32
1200–115200 baud
Yes
Yes (optional)
135 x 92 x 27 mm
-40 to +65 °C
-45 to +85 °C
IP20
12–48 VDC
4.5 W (typical) 6 W (maximum)
CE
RoHS
UL
C US
ATEX/Haz.Loc (Pending)
Netbiter EC350
NB1005 (NB1008 - Without antenna)
5-band 3G/UMTS (WCDMA/FDD): 800/850, 900,
1900, 2100 MHz
Quad-band GSM/GPRS: 850, 900, 1800, 1900 MHz
SMA female
CE
RoHS
UL
C US
Telec
JATE
FCC
IC
PTCRB
RCM
ATEX/Haz.Loc (Pending)
Doc: HMSI-168-92 Rev: 3.10
58
