APPENDIX I: PARAMETER QUICK LIST
Thermostat
Set point adjustment ratio
Differential
High Set Point
Low Set Point
Air Temp Adj .
Alarm
High Alarm delay
Low Alarm delay
High Temp Alarm
Low Temp Alarm
Pulldown delay
Door Open delay
Alarm Buzzer Duration
Auto Clearance of
Alarm/Error
Compressor
Min run time
Min Stop time
Max Off time
Compressor door open
delay
Error run time
Error stop time
Minimum Cutin voltage
Minimum cut-out voltage
Maximum voltage
Power On Delay
Power Factor
Power-on temperature
ERC 102 Reference manual – APPENDIX I: PARAMETER QUICK LIST
ERC menu
Description
code
tHE Thermostat settings
SPr Current setpoint adjustment value diF * SPr
diF Thermostat differential
HSE Upper limit of thermostat set point
LSE Lower limit of thermostat set point
tAd Applies to non-Danfoss temperature sensors only
ERC menu
Description
code
ALA Alarm settings
Htd Alarm delay on high temperature
Ltd Alarm delay on low temperature
HAt Alarm is activated above this temperature (Celsius)
LAt Alarm is activated below this temperature (Celsius)
Pdd Alarm delay during pulldown (0-960 minutes) (high temperature only)
dod Alarm delay for door open (0-60 minutes)
Abd Alarm buzzer duration in minutes (0=no buzzer)
ACA yES: alarm auto-clears if system returns to normal; nO : alarm state maintained regardless
ERC menu
Description
code
CoP Compressor settings
Crt Minimum time compressor must run 0-30 minutes
CSt Min time compressor must idle 0-30 minutes
Cot Max time compressor must idle 0-480 minutes
Cdd Minutes before compressor stops when door opened
Ert Compressor run time if temperature sensor is not working (0-60 minutes)
ESt Compressor stop time if temperature sensor is not working (0-60 minutes)
uLi When compressor is off: Lowest compressor start voltage (0-270 V)
uLo When compressor is on: Lowest operation voltage (0-270 V)
uHi When compressor is on: Highest operation voltage (0-270 V)
Pod Delay in seconds after power-on before outputs active (change with care)
PFA Phasic angle in degrees . Changing this may give decreased relay lifetime
Pot If the temperature of compressor at power-on exceeds this then Power On Delay does not apply
45
