Operating Guide

ECL Comfort 120 controller and app

1.0 Table of Contents

1.0 Table of Contents ............................................. 1

1.1

Important safety and product information. . . . . . . . . . . . . . . . . . . . 2

2.0 Daily use ......................................................... 4

2.1

A general overview: What do the symbols mean? . . . . . . . . . . . 4

2.2

How to navigate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

2.3

Operating the ECL 120 via LED indication . . . . . . . . . . . . . . . . . . . . . 6

2.4

Operating the ECL 120 with an app . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

2.5

Master - slave connectivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

2.6

Application update . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

AQ428842090782en-010102 | 1

Need help?

Do you have a question about the ECL Comfort 120 and is the answer not in the manual?

Questions and answers

Summary of Contents for Danfoss ECL Comfort 120

Page 1: Table Of Contents
Operating Guide ECL Comfort 120 controller and app 1.0 Table of Contents 1.0 Table of Contents ..........1 Important safety and product information....2 2.0 Daily use ............
Page 2: Important Safety And Product Information
Interaction with the ECL Comfort 120 controller This Operating Guide is associated with the ECL Comfort 120 controller (code no. 100B1200, 100B1600, 100B1601, 100B1603). The ECL Comfort 120 is a universal 1-circuit controller for use in district heating substations, district heating-based installations and boiler installations.
Page 3 Fuse should be designed according to max. power draw of controller. Safety Note The ECL Comfort 120 controller shall be mounted in such a way that a safety distance of 20 cm is always kept. This symbol indicates that this particular piece of information should be read with special attention.
Page 4: Daily Use
Operating Guide ECL Comfort 120 controller and app 2.0 Daily use 2.1 A general overview: What do the symbols mean? Symbol Description Operating modes & statuses Interaction button • Short press: Press shorter than 2 seconds • Long press: Press longer than 2 seconds •...
Page 5: How To Navigate
Operating Guide ECL Comfort 120 controller and app 2.2 How to navigate The ECL Comfort 120 controller has several different operation modes that are also indicated through LEDs in the front panel. It is possible to select different modes through buttons or through the dedicated application ECL GO.
Page 6: Operating The Ecl 120 Via Led Indication
Operating Guide ECL Comfort 120 controller and app 2.3 Operating the ECL 120 via LED indication To change the mode without a smart device and application, a button must be pressed. Each short press will change the operating mode. Operating modes & illustrations Mode no.
Page 7 Operating Guide ECL Comfort 120 controller and app 2.3.1 Boost function By means of the boost function the supply temperature can be Boost indication increased for a set value and time. The boost function can be used in automatic / scheduler mode or in constant temperature mode.
Page 8 Operating Guide ECL Comfort 120 controller and app 2.3.3 Alarm or error indication In case of faulty / missing sensor the system LED is blinking red. Alarm is active If a mandatory sensor is detected as missing or faulty the controller will stop and the error LED will be ON.
Page 9: Operating The Ecl 120 With An App
Operating Guide ECL Comfort 120 controller and app 2.4 Operating the ECL 120 with an app To operate the ECL 120 with an app the operator must install a Downloading app to smart device dedicated application named ECL GO which can be linked from the QR code presented to the right.
Page 10: Master - Slave Connectivity
Polarity A and B or + or – on controllers must be respected. Master controllers must be set up to broadcast data in local communication. Up to 20 ECL Comfort 120 controllers can be connected in a local ECL network. Settings and addressing must be done via mobile phones app.
Page 11: Application Update
Operating Guide ECL Comfort 120 controller and app 2.6 Application update The controller application can be updated when connected to Application update is ongoing the mobile application. After the process of application update is activated, the user will be guided through and the led indication will be represented according to the picture to the right.
