APPENDIX II: CODE NUMBERS AND LENGHTS
Type
GDM-front
ERC 102C RED LED without buzzer
ERC 102D RED LED without buzzer
ERC 102C BLUE LED without buzzer
ERC 102D BLUE LED without buzzer
CFF-front
ERC 102C RED LED with buzzer
ERC 102D RED LED with buzzer
ERC 102C BLUE LED with buzzer
ERC 102D BLUE LED with buzzer
Light-sensors
Light sensor, 1000 mm (C3), 3-pole
Light sensor, 2000 mm (C3), 3-pole
Light sensor, 3000 mm (C3), 3-pole
Door-sensors
Door-sensor, 1000 mm (C4), 3-pole
Door-sensor, 2000 mm (C4), 3-pole
Door-sensor, 3000 mm (C4), 3-pole
Temperature sensors
PVC Standard (C1), 470 mm, 3-pole
PVC Standard (C1), 1000 mm, 3-pole
PVC Standard (C1), 1500 mm, 3-pole
PVC Standard (C1), 2000 mm, 3-pole
PVC Standard (C1), 2200 mm, 3-pole
PVC Standard (C1), 3000 mm, 3-pole
Note: For more information about temperature sen-
sor types and connectors, please refer to Danfoss'
technical brochure "NTC type temperature sensors
for ETC & ERC controllers"
Code no . I-Pack
Approvals
230V, CQC/UL/CE
080G3102
080G3103
080G3106
080G3107
080G3113
080G3112
080G3116
080G3117
080G3311
080G3313
080G3315
080G3332
080G3334
080G3336
077F8751
077F8757
077F8761
077F8765
077F8767
077F8769
ERC 102 Reference manual – APPENDIX II: CODE NUMBERS AND LENGHTS
Type
Defrost sensors*
PVC Standard (C2), 470 mm, 2-pole
PVC Standard (C2), 1000 mm, 2-pole
PVC Standard (C2), 1500 mm, 2-pole
PVC Standard (C2), 2000 mm, 2-pole
PVC Standard (C2), 3000 mm, 2-pole
PVC Standard (C3), 470 mm, 3-pole
PVC Standard (C3), 1000 mm, 3-pole
PVC Standard (C3), 1500 mm, 3-pole
PVC Standard (C3), 2000 mm, 3-pole
PVC Standard (C3), 2200 mm, 3-pole
PVC Standard (C3), 3000 mm, 3-pole
Other sensors
TPFE low temp (C1), 1000 mm, 3-pole
TPFE low temp (C1), 2000 mm, 3-pole
TPE precision (C1), 500 mm, 3-pole
TPE precision (C1), 1000 mm, 3-pole
TPE precision (C1), 1500 mm, 3-pole
TPE precision (C1), 2000 mm, 3-pole
TPE precision (C1), 2500 mm, 3-pole
TPE precision (C1), 3000 mm, 3-pole
Clamps
Black (2 needed per controller)
Programming
OEM Docking station, production line
Gateway incl USB Cable, R&D
Copy Stick EKA-183A
C: connector type
* Defrost sensors can also be used as condenser
sensors. .
Code no . I-Pack
Approvals
230V, CQC/UL/CE
077F8780
077F8786
077F8790
077F8794
077F8798
077F8750
077F8756
077F8760
077F8764
077F8766
077F8768
077F8657
077F8665
077F8724
077F8725
077F8726
077F8727
077F8728
077F8729
080G3308
080G9701
080G9711
080G9740
