  • Page 1 Operating Guide ECL Comfort 110, application 130 (valid as of software version 1.08) English version www.danfoss.com...
  • Page 2 The warning sign is used to emphasize special conditions that should be taken into consideration. This symbol indicates that this particular piece of information should be read with special attention. 2 | © Danfoss | 2016.05 VI.KT.G6.02...

  • Page 3: Table Of Contents

    Ramp (reference ramping) 5013 Optimizer (optimizing time constant) 5014 Based on (optimization based on room / outdoor temp.) 5020 Total stop 5021 S1 T filter (outdoor temp. filter) 5081 Cut-out (limit for heating cut-out) 5179 VI.KT.G6.02 © Danfoss | 2016.05 | 3...
  • Page 4 Electrical connections - 24 V a.c. - in general Connecting the temperature sensors and the ECL BUS How to identify your system type Adapting the ECL Comfort 110 controller Manual control Placing the temperature sensors Connecting the room panel / remote control...

  • Page 5: Introduction

    • Maintenance • Installation • Check Basic principles of application 130 for ECL Comfort 110 Typically, the flow temperature is always adjusted according to your requirements. The flow temperature sensor (S3) is the most important sensor. The desired flow temperature at S3 is calculated in the ECL Comfort controller, based on the outdoor temperature (S1).

  • Page 6: Settings Overview

    ECL address (master / slave address) 7199 Type 7600 Code no. 8300 XXXX Ver. (version no.) 8301 XXXX Backlight (display brightness) 8310 Contrast (display contrast) 8311 Language 8315 English MOD address (MODBUS address) 8320 6 | © Danfoss | 2016.05 VI.KT.G6.02...

  • Page 7: Daily Use

    Actual room temperature S2 des. T Desired room temperature S3 act. T Actual flow temperature S3 des. T Desired flow temperature S4 act. T Actual return temperature S4 lim. T Desired return temperature limitation VI.KT.G6.02 © Danfoss | 2016.05 | 7...

  • Page 8: Select Control Mode

    COMFORT< Wednesday Change the mode (AUTO, COMFORT, SETBACK, or STANDBY). Set your personal schedule It is only possible to set the personal schedules if the ECL Comfort 110 controller has a built-in ECA 110 timer program. Wednesday < 04-01-12 8:32 This display will show the current day and time.
  • Page 9 The schedule has always two comfort periods a day. The start and stop times can be set in half-hourly intervals (30 min.). To arrange only one comfort period on a day: Set Start2 and Stop2 times to the same time value. VI.KT.G6.02 © Danfoss | 2016.05 | 9...

  • Page 10: Maintenance

    It is only necessary to set the correct date and time in connection with the first use of the ECL Comfort 110 controller or after a power break of more than 36 hours (see the chapter Adapting the ECL Comfort 110 controller).

  • Page 11: Slope 2175

    For quick setting, the graph can be used. The graph is intended for a T of 20 °C. If the room design data from example I is used, the slope will be approx. 1.7. VI.KT.G6.02 © Danfoss | 2016.05 | 11...
  • Page 12 This controller is factory set for radiator systems, which typically are high flow temperature systems. To control floor heating systems, which typically are low flow temperature systems, you need to change the ‘Slope’ according to your type of system (typical setting: 0.6). 12 | © Danfoss | 2016.05 VI.KT.G6.02...

  • Page 13: Displace (Parallel Displacement) 2176

    Factory setting 10 ... 150 °C 90 °C Choose the allowed max. flow temperature for your system. Adjust the factory setting, if required. The setting for ‘Temp. max.’ has higher priority than ‘Temp. min.’. VI.KT.G6.02 © Danfoss | 2016.05 | 13...

  • Page 14: Room T Limit (Room Temperature Limitation) 3000

    The ‘Gain - max.’ is set to -4.0. The ‘Gain - min.’ is set to 0.0. The ‘Slope’ is 1.8. Result: The desired flow temperature is changed by 2 x -4.0 x 1.8 = -14.4 degrees. 14 | © Danfoss | 2016.05 VI.KT.G6.02...
  • Page 15 The ‘Gain - max.’ is set to -3.5. The ‘Gain - min.’ is set to 2.0. The ‘Slope’ is 1.8. Result: The desired flow temperature is changed by 2 x (-3.5) x 1.8 = -12.6 degrees. VI.KT.G6.02 © Danfoss | 2016.05 | 15...

  • Page 16: Intgr. Time (Time Constant For Room Temp.) 3015

    Determines how much the flow temperature will be influenced (increased) if the room temperature is lower than the desired room temperature (P control). 0.0: The room temperature has no influence. 9.9: The room temperature has a big influence. 16 | © Danfoss | 2016.05 VI.KT.G6.02...

  • Page 17: Return T Limit (Return Temp. Limitation) 4000

    When the return temperature falls below or gets higher than the set value, the controller automatically changes the desired flow temperature to obtain an acceptable return temperature. The influence is set in lines 4035 and 4036. VI.KT.G6.02 © Danfoss | 2016.05 | 17...

  • Page 18: Gain - Max. (Return Temp. Limitation - Max. Influence) 4035

    The desired flow temperature is increased, when the return temperature gets below the set limit. Influence lower than 0: The desired flow temperature is decreased, when the return temperature gets below the set limit. 18 | © Danfoss | 2016.05 VI.KT.G6.02...

  • Page 19: Intgr. Time (Time Constant For Return Temp. Limitation) 4037

    Choose whether the return temperature limitation should overrule the set min. flow temperature ‘Temp. min.’ (line 2177). The min. flow temperature limit is overruled. OFF: The min. flow temperature limit is not overruled. VI.KT.G6.02 © Danfoss | 2016.05 | 19...

  • Page 20: Optimize 5000

    (max. 1 hour). At optimizing the boost is active in the optimization period (line 5014). If a room temperature sensor or a room panel / remote control is connected, the boost stops when the room temperature is reached. 20 | © Danfoss | 2016.05 VI.KT.G6.02...

  • Page 21: Ramp (Reference Ramping) 5013

    The value consists of a two digit number. The two digits have the following meaning: Left digit Heat accumulation of the building System type light medium Radiator systems heavy medium Floor heating systems heavy VI.KT.G6.02 © Danfoss | 2016.05 | 21...

  • Page 22: Based On (Optimization Based On Room / Outdoor Temp.) 5020

    Result: The setting is to be changed to 25. It is only possible make use of ‘Optimize’ if the ECL Comfort 110 controller has a built-in ECA 110 timer program or is connected to an ECA 61. Based on (optimization based on room / outdoor temp.)

  • Page 23: Total Stop 5021

    Time S1 T filter (outdoor temp. filter) 5081 Setting range Factory setting 1 ... 200 Dampens the measured outdoor temperatures by the set factor. Fast (low filter constant) 200: Slow (high filter constant) VI.KT.G6.02 © Danfoss | 2016.05 | 23...

  • Page 24: Cut-Out (Limit For Heating Cut-Out) 5179

    The heating cut-out is only active when the controller mode is AUTO (scheduled operation). When the limit value is set to OFF, there is no heating cut-out. 24 | © Danfoss | 2016.05 VI.KT.G6.02...

  • Page 25: Control Param. (Control Parameters) 6000

    5 ... 250 s 35 s ‘M1 run’ is the time it takes the controlled unit to move from fully closed to fully open position. Set the ‘M1 run’ according to the example. VI.KT.G6.02 © Danfoss | 2016.05 | 25...

  • Page 26: Nz (Neutral Zone) 6187

    When the actual flow temperature is within the neutral zone, the controller does not activate the motorized control valve. The neutral zone is symmetrical around the desired flow temperature value, i.e. half the value is above and half the value is below this temperature. 26 | © Danfoss | 2016.05 VI.KT.G6.02...
  • Page 27 ‘Tn’ = 0.85 x critical time period ‘Xp’ = 2.2 x proportional band value in the critical time period. If the regulation seems to be too slow, you can decrease the proportional band value by 10%. VI.KT.G6.02 © Danfoss | 2016.05 | 27...

  • Page 28: Application 7000

    Factory setting GEAR / ABV GEAR Choose the actuator type for your valve. GEAR: Gear motor ABV: Thermo actuator (Danfoss type ABV) Control parameters (lines 6174-6187) are overruled if thermo actuator is chosen (ABV). 28 | © Danfoss | 2016.05 VI.KT.G6.02...

  • Page 29: Dhw Prior. (Closed Valve / Normal Operation) 7052

    The circulation pump is ON when the outdoor temperature is below the set value. Under normal conditions, your system is not frost protected if your setting is below 0 °C or OFF. For water-based systems, a setting of 2 °C is recommended. VI.KT.G6.02 © Danfoss | 2016.05 | 29...

  • Page 30: P1 Heat T (Heat Demand) 7078

    The controller's schedule is not overridden. SETBACK: The controller is in setback mode when terminals 11 and 12 are short-circuited. COMFORT: The controller is in comfort mode when terminals 11 and 12 are short-circuited. 30 | © Danfoss | 2016.05 VI.KT.G6.02...

  • Page 31: Knee Point 7162

    Setting range Factory setting 0 ... 15 This settting is relevant if more controllers are working in the same ECL Comfort system (connected via the ECL BUS) and / or ECA units are connected. VI.KT.G6.02 © Danfoss | 2016.05 | 31...

  • Page 32: Type 7600

    Factory settings are restored. All personal settings will be deleted. It is recommended to make a note of your personal settings in the ‘Settings overview’ for future use. The application can not be changed from 116 to 130 or vice versa if the ECL Comfort 110 is pre-programmed from the substation-builder.

  • Page 33: Service 8000

    The brightness of the display can be adjusted. OFF: No backlight. Weak backlight. Strong backlight. Contrast (display contrast) 8311 Setting range Factory setting 0 ... 20 The contrast of the display can be adjusted. High contrast Low contrast VI.KT.G6.02 © Danfoss | 2016.05 | 33...

  • Page 34: Language 8315

    MOD address (MODBUS address) 8320 Setting range Factory setting 0 ... 247 Set the MODBUS address if the controller is part of a MODBUS network. Assign the MODBUS addresses within the stated setting range. 34 | © Danfoss | 2016.05 VI.KT.G6.02...

  • Page 35: Installation

    93 x 139 mm. Insert the controller into the panel cut-out and fix it with the clamp which is placed horisontally on the controller. Establish the electrical connections. For further details on mounting, see the mounting guide. VI.KT.G6.02 © Danfoss | 2016.05 | 35...

  • Page 36: Electrical Connections - 230 V A.c. - In General

    Circulation pump - neutral Circulation pump - live (relay R1) 4 (2) A Not to be used Not to be used Wire cross section: 0.5 - 1.5 mm Incorrect connection can damage the TRIAC outputs. 36 | © Danfoss | 2016.05 VI.KT.G6.02...

  • Page 37: Electrical Connections - 24 V A.c. - In General

    Not to be used Not to be used Phase for circulation pump (relay R2) Relay R2 4 (2) A Wire cross section: 0.5 - 1.5 mm Incorrect connection can damage the TRIAC outputs. VI.KT.G6.02 © Danfoss | 2016.05 | 37...

  • Page 38: Connecting The Temperature Sensors And The Ecl Bus

    Wire cross section for sensor connections: 0.4 - 0.75 mm Total cable length: Max. 125 m (all sensors incl. the ECL BUS) Cable lengths of more than 125 m may cause noise sensibility (EMC). 38 | © Danfoss | 2016.05 VI.KT.G6.02...

  • Page 39: How To Identify Your System Type

    Heating system 1: District heating circuit with heat exchanger Heating system 2: District heating circuit with direct connection VI.KT.G6.02 © Danfoss | 2016.05 | 39...
  • Page 40 Installation Heating system 3: Boiler-based heating circuit 40 | © Danfoss | 2016.05 VI.KT.G6.02...

  • Page 41: Adapting The Ecl Comfort 110 Controller

    Installation Adapting the ECL Comfort 110 controller When you switch on the controller the first time, it will ask you to choose language (default language is English). Language English Choose your language. Accept and go to the next menu. When the language is chosen, the controller will ask for date and time setting.

  • Page 42: Manual Control

    Manual mode Pump P1 is OFF ( Pump Select control mode. Mode MANUAL< Wednesday Manual mode should only be used for maintenance purposes. In manual mode all control and safety functions are deactivated! 42 | © Danfoss | 2016.05 VI.KT.G6.02...

  • Page 43: Placing The Temperature Sensors

    Place the sensor max. 15 cm from the mixing point. In systems with heat exchanger, Danfoss recommends that the ESMU-type to be inserted into the exchanger flow outlet. Make sure that the surface of the pipe is clean and even where the sensor is mounted.

  • Page 44: Connecting The Room Panel / Remote Control

    The ECA 61 is activated by the setting in line 7010. The ECA 61 is powered by the ECL BUS which means that the BUS must be active. The BUS is activated by setting the controller address to 15 (line 7199). 44 | © Danfoss | 2016.05 VI.KT.G6.02...

  • Page 45: Checklist, Electrical Connections

    Choose manual operation as controller mode. Check that valves open and close, and that required controlled units (pump etc.) start and stop when operated manually. Check that the temperatures shown in the display match the actual sensors. VI.KT.G6.02 © Danfoss | 2016.05 | 45...

  • Page 46: Frequently Asked Questions

    A PI control does the same as a P control, but the offset will disappear over time. A long ‘Intgr. time’ will give a slow but stable control, and a short ‘Intgr. time’ will result in a fast control but with a higher risk of oscillations. 46 | © Danfoss | 2016.05 VI.KT.G6.02...

  • Page 47: Definitions

    Temperature measured in the flow at any time. Heating circuit The circuit for heating the room / building. Heat curve A curve showing the relationship between actual outdoor temperature and required flow temperature. VI.KT.G6.02 © Danfoss | 2016.05 | 47...
  • Page 48 Flow temperature control based on the outdoor temperature. The control is related to a user-defined heat curve. The definitions apply to the Comfort 110 series. Consequently, you might come across expressions that are not mentioned in your guide. 48 | © Danfoss | 2016.05 VI.KT.G6.02...
  • Page 49 VI.KT.G6.02 © Danfoss | 2016.05 | 49...
  • Page 50 50 | © Danfoss | 2016.05 VI.KT.G6.02...
  • Page 51 Disposal instruction: This product should be dismantled and its components sorted, if possible, in various groups before recycling or disposal. Always follow the local disposal regulations. VI.KT.G6.02 © Danfoss | 2016.05 | 51...

  • Page 52: *Viktg602

    *087R9781* *VIKTG602* 52 | © Danfoss | DHS-SRMT/DK | 2016.05 VI.KT.G6.02...
