Quick Menu
Item Number
1
2
3
4
5
6
7
8
9
10
11
12
During programming of parameters, mo-
tor may start. Be certain no one is in area
of motor or driven equipment when
changing parameters.
To Enter or Change Quick Menu Parameter
Data
Enter or change parameter data or settings in
accordance with the following procedure.
1. Press Quick Menu key.
2. Use '+' and '-' keys to find parameter you
chose to edit.
3. Press Change Data key.
4. Use '+' and '-' keys to select correct
parameter setting. To move to a different digit
within parameter, use
Flashing underline indicates digit selected to
change.
MG.60.G2.02 - VLT is a registered Danfoss Trademark
Table 1 Quick Menu Items Description
Parameter Name Description
001 Language Selects language used for all displays.
Sets output characteristics of drive based on kW (HP) of
102 Motor Power
motor. See Table 2 to convert HP to kW.
Sets output characteristics of drive based on voltage of motor.
103 Motor Voltage
104 Motor Sets output characteristics of drive based on nominal
Frequency frequency of motor. This is typically equal to line frequency.
Sets output characteristics of drive based on full load curren
105 Motor Current in amps (FLA) of motor. This sets overload protection for
motor.
106 Motor Nominal Sets output characteristics of drive based on nominal full load
Speed speed of motor.
201 Minimum Sets minimum controlled frequency at which motor will run.
Frequency
202 Maximum Sets maximum controlled frequency at which motor will run.
Frequency
Sets time to accelerate motor from 0 Hz to nominal motor
206 Ramp Up Time
frequency set in Quick Menu Item 4.
207 Ramp Down Sets time to decelerate motor from nominal motor frequency
Time set in Quick Menu Item 4 to 0 Hz.
323 Relay 1
Sets function of high voltage Form C relay.
Function
326 Relay 2
Sets function of low voltage Form A relay.
Function
and arrows.
VLT ® 6000 HVAC
5. Press Cancel key to disregard change, or
press OK key to accept change and enter
new setting.
6. Press Display key to return to normal display.

Example of Changing Parameter Data

Assume parameter 206, Ramp Up Time, is set at 60
seconds. Change the ramp up time to 100 seconds
in accordance with the following procedure.
1. Press Quick Menu key.
2. Press "+" key until you reach Parameter 206,
Ramp Up Time.
3. Press Change Data key.
4. Press key twice – hundreds digit will flash.
5. Press "+" key once to change hundreds digit
to '1.'
6. Press key once to move cursor to tens
digit.
7
