- Page 1 Operating Guide AMI 120 NL-1 / 73694420 AMI 120 NL-1 Stem Travel 5 mm AMI 120 NL-1+ Travel Speed 10 (12) s/mm AB-QM AUTO MAINTENANCE 5-95 % RH 4 – 6 mm × 1 mm no condensing FREE ❶ © Danfoss | 2021.09...
- Page 2 “Off” at terminal block position “1”: Actuator drives up and valve opens, optional terminal 5 closes. ❸ ⑤ ① ❹ ④ ③ ⑤ ② ① ② ② ① ① AMI 120 NL-1 + AB-QM 2 | © Danfoss | 2021.09 AQ315252253183en-010301...
- Page 3 4 and terminal 5, which indicates actuator’s end position travel. Both contacts are normally open. Jumper position setting Do not remove the cover before the power supply is fully switched off. AQ315252253183en-010301 © Danfoss | 2021.09 | 3...
- Page 4 AMI 120 NL-1 ІМПОРТЕР: UA: ТОВ з ІІ «Данфосс ТОВ», вул. Вікентія Хвойки, 15/15/6, м. Київ, 04080, Україна 4 | © Danfoss | DCS-S/SI | 2021.09 73694420 / AQ315252253183en-010301...
