6.2

Rear Panel LEDs

The LEDs on the rear panel are located within the RJ-45 socket.
meaning of each state of the LEDs on the rear panel.
Label Type
Ethernet
ETH-1
Status
6.3

Monitoring the MP-1xx Channels

To monitor the status of the channels:
•
Open the Channel Status screen ( Status & Diagnostics menu > Channel Status ); the
Channel Status screen is displayed.
The color of each channel shows the call status of that channel.
•
Not Connected (FXO only) - indicates that no analog line is connected to this port.
•
Inactive - indicates this channel is currently onhook.
•
Handset Offhook - indicates this channel is offhook but there is no active RTP session.
•
RTP Active - indicates an active RTP stream.
To monitor the details of a channel, take these 2 steps:
In the Channel Status screen, click the numbered icon of the specific channel whose detailed
1.
status you need to check/monitor; the channel-specific Channel Status screen
Click the submenu links to check/view a specific channel's parameter settings.
2.
MP-1xx

Table 6-2: Definition of MP-1xx Rear Panel LED Indicators

Color State
Yellow ON
Red ON

Figure 6-1: MP-1xx/FXS Channel Status Screen

Definition
Ethernet port receiving data
Collision
32
MP-1xx
Table 6-2 describes the
appears.
