Figure 7-8: Auxiliary Files Screen - AudioCodes MP-1xx Fast Track Installation Manual

To save the loaded auxiliary files to flash memory, take these 2 steps:
Click the Save Configuration button on the main menu bar; the 'Save Configuration to the
1.
Flash Memory' screen is displayed.
Note:
Click the Save Configuration button in the middle of the screen; a confirmation message
2.
appears when the save is complete.
Note:
To reset the MP-1xx, take these 2 steps:
Click the Reset button on the main menu bar; the 'Reset' screen is displayed.
1.
Click the Reset button in the middle of the screen; the auxiliary files are saved into flash and
2.
the MP-1xx restarts. This takes approximately 1 minute to complete. When the MP-1xx has
finished restarting, the Ready and LAN LEDs on the front panel are lit green.
MP-1xx

Figure 7-8: Auxiliary Files Screen

Saving an auxiliary file to flash memory may disrupt traffic on the MP-1xx. To
avoid this, disable all traffic on the device before saving to flash memory.
A device reset is required to activate a loaded CPT file, and may be required
for the activation of certain ini file parameters.
38
MP-1xx
Document #: LTRT-61405
