Fast Track Installation Guide
3.2

Restoring Networking Parameters to their Initial State

You can use the 'Reset' button to restore the MP-1xx networking parameters to their factory
default values (described in
Note that the MP-1xx returns to the software version burned in flash. This process also restores
the MP-1xx parameters to their factory settings, therefore you must load your previously backed-
up ini file, or the default ini file (received with the software kit) to set them to their correct values.
To restore networking parameters to their initial state, take these 6
steps:
Disconnect the MP-1xx from the power and network cables.
1.
Reconnect the power cable; the gateway is powered up. After approximately 45 seconds the
2.
Ready LED turns to green and the Control LED blinks for about 3 seconds.
While the Control LED is blinking, press shortly on the reset button (located on the left side
3.
of the front panel); the gateway resets a second time and is restored with factory default
parameters (username: "Admin", password: "Admin").
Reconnect the network cable.
4.
Assigning the MP-1xx IP address (refer to Section
5.
Load your previously backed-up ini file, or the default ini file (received with the software kit).
6.
To load the ini file via the Embedded Web Server, refer to Section
3.3

Accessing the Embedded Web Server

To access the Embedded Web Server, take these 4 steps:
Open a standard Web-browsing application such as Microsoft™ Internet Explorer™ (Version
1.
6.0 and higher) or Netscape™ Navigator™ (Version 7.0 and higher).
In the URL field, specify the IP address of the MP-1xx (e.g., http://10.1.10.10 for MP-
2.
1xx/FXS); the Embedded Web Server's 'Enter Network Password' screen appears, shown in
Figure 3-2.
In the 'User Name' and 'Password' fields, enter the username (default: "Admin") and
3.
password (default: "Admin"). Note that the username and password are case-sensitive.
Click OK; the 'Quick Setup' screen is accessed, shown in
4.
(H.323), and
Version 4.4
Table 3-1) and to reset the username and password.

Figure 3-2: Embedded Web Server Login Screen

Figure 3-5 (SIP).
3.1 on page 18).
Figure 3-3
21
3. Configuring the MP-1xx
5 on page 30.
(MGCP), Figure 3-4
March 2005
