Fast Track Installation Guide
In the 'Load an ini File' screen, you can now choose to either:
6.
Click Browse and navigate to the ini file; the check box 'Use existing configuration', by
default checked, becomes unchecked. Click Send File ; the ini file is loaded to the MP-
1xx and you're notified as to a successful loading.
Ignore the Browse button (its field remains undefined and the check box 'Use existing
configuration' remains checked by default).
Ignore the Browse button and uncheck the 'Use existing configuration' check box; no ini
file is loaded, the MP-1xx uses its factory-preconfigured values.
You can now choose to either:
Click Cancel ; the MP-1xx resets utilizing the cmp, ini and all other configuration files
that were previously stored in flash memory. Note that these are NOT the files you
loaded in the previous Wizard steps.
Click Reset ; the MP-1xx resets, utilizing the new cmp and ini file you loaded up to now
as well as utilizing the other configuration files.
Click Back ; the 'Load a cmp file' screen is reverted to; refer to
Click Next ; the 'Load a CPT File' screen opens, refer to
file or any other auxiliary file listed in the Wizard is optional.
Follow the same procedure you followed when loading the ini file (refer to Step 6). The same
7.
procedure applies to the 'Load a VP file' (not applicable to the MP-1xx gateway) screen and
'Load a coefficient file' screen.
Version 4.4

Figure 7-4: Load an ini File Screen

Figure 7-5: Load a CPT File Screen

35
7. Software Update
Figure 7-2.
Figure 7-5; Loading a new CPT
March 2005
