In the 'Endpoint Name' field, enter an intuitive endpoint name. Ensure that the endpoint
8.
name you choose is the one that the Call Agent works with.
Click the Reset button and click OK in the prompt; The MP-1xx applies the changes and
9.
restarts. This takes approximately 1 minute to complete. When the MP-1xx has finished
restarting, the Ready and LAN LEDs on the front panel are lit green.
Note:
3.4.2

Configuring Basic H.323 Parameters

After accessing the Embedded Web Server (refer to Section
Setup' screen is displayed, shown in
To configure basic H.323 parameters, take these 7 steps:
If the MP-1xx is behind a router with NAT enabled, perform the following procedure. If it isn't,
1.
leave the 'NAT IP Address' field undefined.
Determine the "public" IP address assigned to the router (by using, for instance, router
Web management). Enter this public IP address in the 'NAT IP Address' field.
Enable the DMZ configuration on the residential router for the LAN port where the MP-
1xx gateway is connected. This enables unknown packets to be routed to the DMZ port.
When working with a Gatekeeper, set 'Working with Gatekeeper' field, under 'H.323
2.
Parameters', to 'Yes' and enter the IP address of the primary Gatekeeper in the field
'Gatekeeper IP Address'. When no Gatekeeper is used, the internal routing table is used to
route the calls.
Leave parameter 'Enable Annex D/T.38 FAX Relay' at its default unless your technical
3.
requirements differ.
MP-1xx
MGCP Users should continue with Section
on page 29.
Figure

Figure 3-4: MP-1xx H.323 Quick Setup Screen

4 Changing the MP-1xx Username
3.3
3-4.
24
MP-1xx
on page 21) the H.323 'Quick
