3

Configuring the MP-1xx

The MP-1xx is supplied with application software already resident in its flash memory (with
factory default parameters).
Section 3.1
page 22 describes how to set up the MP-1xx with basic parameters using a standard Web
browser (such as Microsoft
Note:
3.1

Assigning the MP-1xx IP Address

To assign an IP address to the MP-1xx use one of the following methods:
•
HTTP using a Web browser (refer to Section
•
BootP (refer to Section
•
DHCP (refer to the Mediant 2000 User's Manual).
•
Serial communication software (e.g., HyperTerminal
232 port (refer to Section
The default networking parameters are show in
You can use the 'Reset' button to restore the MP-1xx networking parameters to their factory
default values (refer to Section
FXS or FXO
FXS
FXO
MP-1xx default subnet mask is 255.255.0.0, default gateway IP address is 0.0.0.0
3.1.1

Assigning an IP Address Using HTTP

To assign an IP address using HTTP, take these 8 steps:
Connect your computer to the MP-1xx. Either connect the network interface on your
1.
computer to a port on a network hub/switch (refer to
cable), or use an Ethernet cross-over cable to directly connect the network interface on your
computer to the RJ-45 jack on the MP-1xx.
Change your PC's IP address and subnet mask to correspond with the MP-1xx factory
2.
default IP address and subnet mask, shown in
address and subnet mask of your PC, refer to Windows™ Online Help (Start>Help).
Access the MP-1xx Embedded Web Server (refer to Section
3.
In the 'Quick Setup' screen, set the MP-1xx 'IP Address', 'Subnet Mask' and 'Default
4.
Gateway IP Address' fields under 'IP Configuration' to correspond with your network IP
settings. If your network doesn't feature a default gateway, enter a dummy value in the
'Default Gateway IP Address' field.
Click the Reset button and click OK in the prompt; the MP-1xx applies the changes and
5.
restarts. This takes approximately 1 minute to complete. When the MP-1xx has finished
restarting, the Ready and LAN LEDs on the front panel are lit green.
MP-1xx
below describes how to assign an IP address to the MP-1xx, while Section
TM
Internet Explorer).
Section 3.1 applies equally to MGCP, H.323 and SIP.
3.1.2 on page 19).
3.1.3
3.2 on page 21).

Table 3-1: MP-1xx Default Networking Parameters

3.1.1 below).
TM
) connected to the MP-1xx via the RS-
on page 20).
Table 3-1.
Default Value
10.1.10.10
10.1.10.11
Table 2-3
Table 3-1. For details on changing the IP
18
on page 13 - RJ-45 Ethernet
3.3 on page 21).
Document #: LTRT-61405
MP-1xx
3.4 on
