- Page 1 MediaPack Series MP-11x & MP-124 Analog VoIP Gateways Installation Manual Version 6.6 April 2012 Document #: LTRT-59815...
-
Page 3: Table Of Contents
Hardware Installation Manual Contents Table of Contents Introduction ......................7 MP-11x Hardware Installation ................9 Physical Description ....................9 2.1.1 MP-11x Front Panel (LEDs Description) ..............9 2.1.2 MP-11x Rear Panel (Ports Description) ..............10 Unpacking and Checking Package Contents ............10 Mounting MP-11x .................... - Page 4 MediaPack Series List of Figures Figure 2-1: MP-11x Front Panel (e.g., MP-118) ..................9 Figure 2-2: MP-11x Rear Panel (e.g., MP-118) ..................10 Figure 2-3: MP-11x Underside ....................... 11 Figure 2-4: 19-inch Rack Shelf for MP-11x ................... 12 Figure 2-5: MP-11x Rack Mount Installation ..................13 Figure 2-6: RJ-45 Connector Pinouts for Ethernet Connection .............
-
Page 5: Weee Eu Directive
This document is subject to change without notice. Date Published: April-18-2012 Trademarks AudioCodes, AC, AudioCoded, Ardito, CTI2, CTI², CTI Squared, HD VoIP, HD VoIP Sounds Better, InTouch, IPmedia, Mediant, MediaPack, NetCoder, Netrake, Nuera, Open Solutions Network, OSN, Stretto, TrunkPack, VMAS, VoicePacketizer, VoIPerfect, VoIPerfectHD, What’s Inside Matters, Your Gateway To VoIP and 3GX are trademarks or... -
Page 6: Regulatory Information
MediaPack Series Regulatory Information The Regulatory Information can be viewed at http://www.audiocodes.com/downloads. Related Documentation Document Name SIP Product Reference Manual SIP Release Notes MP-11x & MP-124 SIP User's Manual MP-124 AC SIP Fast Track Guide MP-124 DC SIP Fast Track Guide... -
Page 7: Introduction
Hardware Installation Manual 1. Introduction Introduction This document describes the hardware installation of the MediaPack MP-1xx product series. The MP-1xx series includes the following models: MP-11x: • MP-112 • MP-114 • MP-118 MP-124 The table below compares the telephony support between these MP1xx models: Table 1-1: MP-1xx Model Telephony Support Combined Number of... - Page 8 MediaPack Series Reader’s Notes Hardware Installation Manual Document #: LTRT-59815...
-
Page 9: Mp-11X Hardware Installation
Hardware Installation Manual 2. MP-11x Hardware Installation MP-11x Hardware Installation This chapter describes the MP-11x hardware installation. Physical Description The subsections below provide a physical description of the front and rear panels of the MP-11x. 2.1.1 MP-11x Front Panel (LEDs Description) The device's front panel provides LEDs for indicating various operating statuses. -
Page 10: Mp-11X Rear Panel (Ports Description)
MediaPack Series Color State Definition Power Green Power is received by the device. Failure / disruption in the AC power supply or power is currently not being supplied to the device through the AC power supply entry. 2.1.2 MP-11x Rear Panel (Ports Description) The device's rear panel provides the ports for cabling the device to the various interfaces. -
Page 11: Mounting Mp-11X
Small plastic bag containing four anti-slide bumpers for desktop installation. • Regulatory Information document. Check, retain, and process any documents. Notify AudioCodes or your local supplier of any damage or discrepancies. Mounting MP-11x The device can be mounted in one of the following ways: ... -
Page 12: Desktop Mounting
2.3.3 19-inch Rack Mounting MP-11x can be installed in a standard 19-inch rack by placing it on an AudioCodes' 19-inch rack-mounting shelf (special customer order) that must be pre-installed in a rack. The shelf can hold up to two MP-11x devices. The rack-mounting shelf can be ordered separately from AudioCodes. -
Page 13: Figure 2-5: Mp-11X Rack Mount Installation
Hardware Installation Manual 2. MP-11x Hardware Installation To install MP-11x in a 19-inch rack: Attach one or two MP-11x devices to the shelf using the shelf-to-device screws (supplied). Position the shelf in the rack and align its side holes with the rack frame holes. Attach the shelf to the rack using four standard rack screws (not supplied). -
Page 14: Cabling Mp-11X
MediaPack Series Cabling MP-11x This section describes the MP-11x cabling procedures: To cable MP-11x: Connecting to the Ethernet network – see 'Connecting MP-11x to the Network' on page Connecting to FXS/FXO devices – see 'Connecting MP-11x to FXS/FXO Devices' on page ... -
Page 15: Connecting Mp-11X To Fxs Interfaces
Hardware Installation Manual 2. MP-11x Hardware Installation 2.4.2 Connecting MP-11x to FXS Interfaces The procedure below describes how to cable the MP-11x FXS interfaces. Warnings: • Ensure that you connect FXS ports only to analog telephones; otherwise, damage to MP-11x may occur. •... -
Page 16: Connecting Mp-11X To Fxo Interfaces
MediaPack Series 2.4.3 Connecting MP-11x to FXO Interfaces The procedure below describes how to cable the MP-11x FXO interfaces. Warnings: • Ensure that you connect FXO ports only to CO/PBX lines; otherwise, damage to MP-11x may occur. • To protect against electrical shock and fire, use a 26 AWG minimum wire to connect FXO ports to the PSTN. -
Page 17: Connecting Mp-11X To Analog Fxs Lifeline Phone
Hardware Installation Manual 2. MP-11x Hardware Installation 2.4.4 Connecting MP-11x to Analog FXS Lifeline Phone The Lifeline provides a wired analog POTS phone connection to any PSTN or PBX FXS port when there is no power or when the network connection fails. Therefore, you can use the Lifeline phone even when MP-11x is not powered or not connected to the network. -
Page 18: Connecting Mp-11X To Computer For Serial Communication
MediaPack Series To cable the combined MP-11x FXS/FXO Lifeline: Connect a fax machine, modem, or phone to each of the FXS ports. Connect an analog PSTN line to each of the FXO ports. Figure 2-14: Lifeline Cabling for FXS and FXO Devices 2.4.5 Connecting MP-11x to Computer for Serial Communication The procedure below describes how to connect the MP-11x serial (RS-232) interface to a... -
Page 19: Figure 2-17: Connecting The Serial Port
Hardware Installation Manual 2. MP-11x Hardware Installation To connect MP-11x to a computer for serial communication: Connect the PS/2 connector on one end of the cable to the MP-11x RS-232 port (labeled RS-232). Figure 2-17: Connecting the Serial Port Connect the DB-9 connector at the other end of the cable to either the COM1 or COM2 RS-232 communication port on your computer. -
Page 20: Connecting Mp-11X To Power
MediaPack Series 2.4.6 Connecting MP-11x to Power MP-11x is powered from a standard alternating current (AC) electrical outlet. Warnings: • The device must be connected only by professional service personnel. • Ensure that the device connects to an electrical socket outlet that provides protective earthing (grounding). -
Page 21: Mp-124 Hardware Installation
Hardware Installation Manual 3. MP-124 Hardware Installation MP-124 Hardware Installation This chapter describes the MP-124 hardware installation. Physical Description The subsections below provide a physical description of the MP-124 front and rear panels. 3.1.1 MP-124 Front Panel The MP-124 front panel, shown in the figure below provides LEDs for indicating various operating statuses, and a reset button. -
Page 22: Mp-124 Rear Panel
MediaPack Series Label Color State Function Channels Green Telephone in off-hook position or ringing. Line malfunction. Normal. 3.1.2 MP-124 Rear Panel The rear panel of the MP-124 provides the port interfaces. The MP-124 is available as either an AC-powered or DC-powered device. ... -
Page 23: Unpacking And Checking Package Contents
Only for DC-powered model: unwired DC terminal block with two crimping screws • Two short equal-length brackets and bracket-to-device screws for 19-inch rack installation. • Regulatory Information document. Check, retain and process any documents. Notify AudioCodes or your local supplier of any damage or discrepancies. Version 6.6 April 2012... -
Page 24: Mounting Mp-124
MediaPack Series Mounting MP-124 MP-124 can be mounted in one of the following ways: Desktop mounting – see 'Desktop Mounting' on page Installed in a standard 19-inch rack – see '19-inch Rack Mounting' on page 3.3.1 Desktop Mounting For MP-124 desktop mounting, no brackets are required. - Page 25 Hardware Installation Manual 3. MP-124 Hardware Installation Rack Mount Safety Instructions When installing the chassis in a rack, implement the following safety instructions: • Elevated Operating Ambient - If installed in a closed or multi-unit rack assembly, the operating ambient temperature of the rack environment may be greater than room ambient.
-
Page 26: Cabling Mp-124
MediaPack Series Cabling MP-124 This section describes the MP-124 cabling procedures: Grounding (earthing) MP-124 – see 'Grounding MP-124' on page Connecting to the Ethernet network – see 'Connecting MP-124 to the Ethernet Network' on page Connecting to FXS analog lines – see 'Connecting MP-124 to FXS Interface' on page ... -
Page 27: Power Surge Protection And Grounding
• As most of the installation is the responsibility of the customer, AudioCodes can assume responsibility for damage only if the customer can establish that MP-124 does not comply to the standards specified above (and MP-124 is within the hardware warranty period). -
Page 28: Figure 3-6: Grounding And Power Surge Protection
MediaPack Series This fixture must be connected alongside or within the Main Distribution Frame (MDF). You must connect the grounding connection of this electrical cabinet to the grounding bus of the electrical circuit board, using AWG wires of at least 10mm and maximum length of 3 meters. -
Page 29: Connecting Mp-124 To The Ethernet Network
Hardware Installation Manual 3. MP-124 Hardware Installation 3.4.2 Connecting MP-124 to the Ethernet Network The procedure below describes how to connect MP-124 directly to the Ethernet network. This cabling requires a crossover Ethernet cable with the following RJ-45 connector pinouts: Figure 3-7: RJ-45 Connector Pinouts for Ethernet Connection ... -
Page 30: Connecting Mp-124 To Fxs Interfaces
MediaPack Series 3.4.3 Connecting MP-124 to FXS Interfaces The MP-124 interfaces with the analog telephone interfaces by connecting to a main distribution frame (MDF), using a 50-pin Telco cable. MP-124 Safety Notice To protect against electrical shock and fire, use a 26 AWG min wire to connect analog FXS lines to the 50-pin Telco connector. -
Page 31: Figure 3-10: Mp-124 In A 19-Inch Rack With Mdf Adaptor
Hardware Installation Manual 3. MP-124 Hardware Installation Insert and fasten the male connector to the female 50-pin Telco connector on the MP-124 rear panel (labeled Analog FXS Lines 1-24). Connect the telephone lines from the MDF adaptor block to a fax machine, modem, or telephones by inserting each RJ-11 connector on the 2-wire line cords of the POTS phones into the RJ-11 sockets on the front of an MDF adaptor block, as shown in the figure below. -
Page 32: Connecting Mp-124 To A Computer For Serial Communication
MediaPack Series 3.4.4 Connecting MP-124 to a Computer for Serial Communication The procedure below describes how to connect the MP-124 to a computer for serial RS-232 communication. This cabling uses a standard, straight-through cable with DB-9 connectors on either end, with the following connector pinouts: Figure 3-11: MP-124 RS-232 Connector Pinouts ... -
Page 33: Connecting Mp-124 To Power
Hardware Installation Manual 3. MP-124 Hardware Installation 3.4.5 Connecting MP-124 to Power MP-124 can be powered either from a standard AC electrical outlet or a 48-VDC power supply. The power configuration depends on the ordered MP-124 model. After powering-up MP-11x, the Ready and Power LEDs on the front panel light up green (after a self-testing period of about two minutes). -
Page 34: Dc Power Supply
MediaPack Series 3.4.5.2 DC Power Supply This section describes cabling of the MP-124 model for 48-VDC power supply. MP-124 DC Safety Notice When connecting MP-124 to a DC power supply, ensure that you adhere to the following safety guidelines: • Connect the device to a safety extra-low voltage (SELV) source that is sufficiently isolated from the mains. - Page 35 Hardware Installation Manual 3. MP-124 Hardware Installation Reader's Notes Version 6.6 April 2012...
- Page 36 Installation Manual Ver. 6.6 www.audiocodes.com...
