Fast Track Installation Guide
Installation and service of this card must only be performed by authorized, qualified service personnel.
The protective earth terminal on the back of the MP-1xx must be permanently connected to protective earth.
The safety status of each port on the gateway is declared and detailed in the table below:
TNV-3: Circuit whose normal operating voltages exceeds the limits for an SELV circuit under normal operating
conditions and on which over voltages from Telecommunication Networks are possible
TNV-2: Circuit whose normal operating voltages exceeds the limits for an SELV circuit under normal operating
conditions and is not subjected to over voltages from Telecommunication Networks
SELV: Safety extra low voltage circuit.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This
equipment generates uses and can and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
9.2

MP-11x FXO

Application of Council Directives :
Standards to which Conformity is Declared :
Manufacturer's Name :
Manufacturer's Address :
Type of Equipment :
Model Numbers :
I, the undersigned, hereby declare that the equipment specified above conforms to the above Directives and Standards.
Signature
I. Zusmanovich, Compliance Engineering Manager
Version 4.4
Safety Notice
Telecommunication Safety
Ports
Ethernet (100 Base-TX)
FXS (ODP P/N's)
FXS
FCC Statement
Declaration of Conformity
73/23/EEC (including amendments),
89/336/EEC (including amendments),
1999/5/EC Annex-II of the Directive
EN55022: 1998, Class B
EN55024:1998
EN61000-3-2: 1995
(including amendments A1: 1998, A2: 1998, A14: 2000)
EN61000-3-3: 1995
EN60950: 2000
TBR-21: 1998
AudioCodes Ltd.
1 Hayarden Street, Airport City, Lod 70151, Israel.
Analog VoIP System.
MP-1xx/FXO
(xx- may represent 02, 04, 08)
th
11 February 2005
Date (Day/Month/Year)
41
9. Regulatory Information
Safety Status
SELV
TNV-3
TNV-2
Airport City, Lod, Israel
Location
March 2005
