Figure 7-2: Load A Cmp File Screen; Figure 7-3: Cmp File Successfully Loaded Into The Mp-1Xx Notification - AudioCodes MP-1xx Fast Track Installation Manual

Click the Start Software Upgrade button; the 'Load a cmp file' screen appears
3.
Note:
Click the Browse button, navigate to the cmp file and click the button Send File ; the cmp file
4.
is loaded to the MP-1xx and you're notified as to a successful loading (refer to

Figure 7-3: cmp File Successfully Loaded into the MP-1xx Notification

Note that the four action buttons ( Cancel , Reset , Back , and Next ) are now activated
5.
(following cmp file loading).
You can now choose to either:
Click Reset ; the MP-1xx resets, utilizing the new cmp you loaded and utilizing the
current configuration files.
Click Cancel ; the MP-1xx resets utilizing the cmp, ini and all other configuration files
that were previously stored in flash memory. Note that these are NOT the files you
loaded in the previous Wizard steps.
Click Back ; the 'Load a cmp File' screen is reverted to; refer to
Click Next ; the 'Load an ini File' screen opens; refer to
or any other auxiliary file listed in the Wizard is optional.
Note that as you progress, the file type list on the left indicates which file type loading is in
process by illuminating green (until 'FINISH').
MP-1xx
When in the Wizard process, the rest of the Web application is unavailable and
the background Web screen is disabled. After the process is completed,
access to the full Web application is restored.

Figure 7-2: Load a cmp File Screen

Figure
34
MP-1xx
(Figure 7-2).
Figure 7-3).
Figure 7-2.
7-4. Loading a new ini file
