Figure 2-7: Rj-45 Ethernet Connector Pinout; Figure 2-8: Rj-11 Phone Connector Pinout; Figure 2-9: 50-Pin Telco Connector (Mp-124/Fxs Only); Figure 2-10: Mp-124 In A 19-Inch Rack With Mdf Adaptor - AudioCodes MP-1xx Fast Track Installation Manual

AC Power Cord
Grounding Strap
MP-1xx

Figure 2-7: RJ-45 Ethernet Connector Pinout

RJ-45 Connector and Pinout
1 2 3 4 5 6 7 8

Figure 2-8: RJ-11 Phone Connector Pinout

RJ-11 Connector and Pinout
1 2 3 4

Figure 2-9: 50-pin Telco Connector (MP-124/FXS only)

25
50

Figure 2-10: MP-124 in a 19-inch Rack with MDF Adaptor

FRONT INPUT
24 line cords
2-wire with RJ-11
connectors
M D F Adaptor Block - rear
Connect to
here
ANALOG LINES 1-20
100 - 250V~
50 - 60Hz 2A
50-pin female
Telco connector
1 - Tx+
4, 5, 7, 8
2 - Tx-
not
3 - Rx+
connected
6 - Rx-
1 - Not connected
2 - Tip
3 -
Ring
4 - Not connected
Pin Numbers
1
26
19-inch Rack

Rear View

REAR OUTPUT
24 wire pairs in
Octopus cable
with 50-pin male
Telco connector
RS-232
1 2 3 4 5
Data Cntrl Ready
CONFIG
Eth 1 Eth 2
RS-232 Cable
14
MP-1xx
Primary
LAN Cable
to Eth 1
Back-up
LAN Cable
to Eth 2
MP-124
Rear View
Document #: LTRT-61405
