Installing the MP-1xx

The equipment must only be installed or serviced by qualified service personnel.
To install the MP-1xx, take these 4 steps:
Unpack the MP-1xx (refer to Section
1.
Check the package contents (refer to Section
2.
Mount the MP-1xx (refer to Section
3.
Cable the MP-1xx (refer to Section
4.
After connecting the MP-1xx to the power source, the Ready and LAN LEDs on the front panel
turn to green (after a self-testing period of about 1 minute). Any malfunction changes the Ready
LED to red (refer to Section
When you have completed the above relevant sections you are then ready to start configuring the
gateway (Section
2.1

Unpacking

To unpack the MP-1xx, take these 6 steps:
Open the carton and remove the packing materials.
1.
Remove the MP-1xx gateway from the carton.
2.
Check that there is no equipment damage.
3.
Check, retain and process any documents.
4.
Notify AudioCodes or your local supplier of any damage or discrepancies.
5.
Retain any diskettes or CDs.
6.
2.2

Package Contents

Ensure that in addition to the MP-1xx, the package contains:
•
AC power cable for the AC power supply option.
•
DC terminal block (MP-124 only, for the DC power supply option).
•
CD (software and documentation).
•
Lifeline cable (RJ-11 adaptor cable for 1 to 2). Supplied with MP-10x/FXS, only.
•
3 brackets (2 short, 1 long) and bracket-to-device screws for 19-inch rack installation option
(MP-10x only).
•
2 short equal-length brackets and bracket-to-device screws for MP-124 19-inch rack
installation.
•
This Fast Track Installation Guide.
