Processor and memory modules have a green LED that lights when the module
passes or completes self-test. These LEDs can be viewed through holes in the
shield of the module enclosure from the front of the cabinet. PCI I/O modules
are not visible but some connectors have LEDs on them. Table 6-1 lists TLSB
and DWLPB, the PCI motherboard, modules showing LED conditions after self-
test. For conditions of LEDs on PCI adapters, see the related documentation.
Table 7–1 LEDs After Self-Test
Module
¹
KN7CG
MS7CC
KFTHA
³
DWLPB
¹ The green LED on the processor module indicates that both CPU chips on a dual–
processor module passed. The LED will be OFF if there is any failure on the
module though it may be configured into the system.
² The green LED on the memory module indicates that self-test completed, not
passed.
³ The DWLPB (the PCI motherboard) has four LEDs. The self-test passed LED is the
second from the hose connection.
Self-Test Passed
Green ON
Green ON
Green ON
Green ON
Self-Test Failed
Green OFF
²
Green OFF or ON
Green OFF
System Self-Test 7-3
