Compaq AlphaServer GS60E Installation Manual page 33

WARNING: Serious injury may result if the cabinet is improperly
handled or proper safety conditions are not met.
Check the cabinet sides, top, front door, and rear panel for damage. If the
cabinet is damaged, do the following:
•
Enter the location and extent of the damage on the LARS report.
•
Notify the customer and your unit manager.
•
Stop unpacking until the customer gives you permission to continue.
1. Using an adjustable wrench, remove the four bolts and shipping brackets
that hold the cabinet leveler feet to the pallet (Figure 3-3).
2. The leveler feet are lowered to the pallet surface for shipping. Using the
adjustable wrench, raise the feet to the upmost position before removing the
system from the pallet (see Section 3.5).
3. Attach the ramps by fitting the prongs into the holes on the front of the
pallet. Place the ramps so that the runners are on the inside. Align the
arrows on the ramps and pallets (see Figure 3-3).
4. With two people working together (one in front and one in back), slowly roll
the cabinet off the pallet down the ramps. Move the cabinet into position.
This should be done on a firm level floor. To avoid static electricity, which
can cause system problems, do not place the system on a carpet.
NOTE: Make sure the space under the cabinet is clear of any debris or
extraneous materials.
Installing the System Cabinet 3-9
