5.1
Connect the Console Terminal
Figure 5-1 shows a system cabinet with a console terminal. Connect the
console terminal to the console terminal port in the system cabinet as
shown in Figure 5-2.
Figure 5–1 System Cabinet, Console Terminal, and Printer
COMPAQ
AlphaServer GS60E
LA75
Companion Printer
d i g i t a l
GS60E51-99
5-2
AlphaServer GS60E Installation Guide
