Cabinet Sizes
Include all cabinets and peripherals when laying out the installation
site. A sample system could include a main cabinet, a maximum of two
expander cabinets, and console devices. Figure 2-1 shows a sample
GS60E system.
Figure 2–1 GS60E Sample System
Expander
System
Cabinet
Cabinet
60 cm (23.6 in)
60 cm (23.6 in)
2-4
AlphaServer GS60E Installation Guide
Expander
Cabinet
60 cm (23.6 in)
GS60E21-99
