8.12 Booting LFU from a CD-ROM

The Loadable Firmware Update (LFU) Utility is on the Alpha CD-ROM
(PN AG-RCFB*-BS). Make sure this CD-ROM is mounted in the CD
drive and then boot LFU.
Example 8–10 AlphaServer GS60E Booting
P00>>> show device
polling for units on isp0, slot 0, bus 0, hose0...
dka400.4.0.0.0
polling for units on isp1, slot 1, bus 0, hose0...
polling for units on isp2, slot 4, bus 0, hose0...
polling for units on isp3, slot 5, bus 0, hose0...
dkd400.4.0.5.0
dkd500.5.0.5.0
P00>>> boot dkd400
Building FRU table. . . . . . . . .
(boot dkd400.4.0.5.0 –flags 0,a0)
SRM boot identifier: scsi 4 0 5 0 400 ef00 81011
boot adapter: isp3 rev 0 in bus slot 5 off of kftia0 in TLSB slot 8
block 0 of dkd400.4.0.5.0 is a valid boot block
reading 1018 blocks from dkd400.4.0.5.0
bootstrap code read in
base = 200000, image_start = 0, image_bytes = 7f400
initializing HWRPB at 2000
initializing page table at 1f2000
initialing machine state
setting affinity to the primary CPU
jumping to bootstrap code
Bootfile:[gs140]gs140_V55_10.exe
***** Loadable Firmware Update Utility *****
----------------------------------------------------------
Function
----------------------------------------------------------
Display
Exit
List
Modify
Show
8-26 AlphaServer GS60E Installation Guide
DKA400
DKD400
DKD500
-fl 0,a0
Description
Displays the system's configuration table.
Return to loadable offline operating environment
Lists the device types and firmware revisions
supported by this revision of LFU.
Modifies port parameters and device attributes.
Displays device mnemonic, hardware and firmware
revisions.
RZ26L 440C
RZD47 440C
RZ26L 440C
