2.5

AC Power Cable and Receptacles

The AC power cable is 4.5 m (15 ft) in length. It consists of three-phase
leads (X, Y, and Z) plus neutral (N) and ground (G).
connectors are shown in Figure 2-4.
Figure 2–4 AC Power Receptacles
120/208 V NOMINAL (50-60 Hz)
NEMA L21-30R
V
PHASE X
NEUTRAL
PHASE Z
2-10 AlphaServer GS60E Installation Guide
202 V NOMINAL (50-60 Hz)
NEMA L21-30R
V
V
PHASE Y
V
380-415 V NOMINAL (50-60 Hz)
IEC 309 TYPE
V
PHASE 3
PHASE 2
NEUTRAL
PHASE 1
GND
AC power
V
PHASE X
PHASE Y
PHASE Z
V
V
V
GS60E24-99
