Check the Delivery Route:
U
Check the height, width, and location of doors and passageways for
adequate clearance.
U
Check floor loading requirements along passageways.
U
Check passageway restrictions such as corners, ramps, or obstructions.
U
Check the size, capacity, and availability of elevators.
Table 2-1 lists the shipping dimensions of the GS60E system and expander
cabinets. These dimensions include the width of the shipping pallet, the height
of the shipping boxes, and the weight of the packing materials.
Table 2-1

Shipping Dimensions and Weights

Height
Cabinet cm (in)
GS60E 194 (76.25)
System
GS60E 194 (76.25)
Expander
ï
System and expander weights are based on a fully configured cabinet.
Width Depth
cm (in) cm (in)
91.5 (36.0) 121.5 (47.9)
91.4 (36.0) 121.5 (47.9)
Weight
ï
kg (lbs)
398 (875)
365 (804)
Site Preparation 2-3
