Troubleshooting The Cisco Rps; Reading The Leds - Cisco Power system Installation Manual

Reading the LEDs

OL-3654-01

Troubleshooting the Cisco RPS

The key to troubleshooting is to isolate the problem to a specific subsystem. Start
by reading the LEDs on the front panel of the Cisco RPS and any error messages
displayed on the external device console. If you are unable to resolve the problem,
refer to the "Getting Technical Support" section on page
This chapter contains the following sections:
Reading the LEDs, page 5-1
•
Displaying Status, page 5-5
•
Error Messages on Cisco 2600 Series and Cisco 3620, Cisco 3640, and
•
Cisco 3725 Routers, page 5-6
• Replacing an External Device, page 5-13
Getting Technical Support, page 5-14
•
The LEDs on the front panel of the Cisco RPS (see
operating condition of the Cisco RPS. Refer to
meaning of various LED colors. When the Cisco RPS is working properly, the
LEDs are solid green. When there is a problem with any component, the related
LED is amber.
Cisco Redundant Power System Hardware Installation Guide
C H A P T E R
5-14.
Figure 5-1) display the current
Table 1-2 on page 1-10
5
for the
5-1
