Chapter 3 Connection Requirements

Ordering Cables

OL-3654-01
Cisco 2500 and Cisco 2600 series routers; Cisco 3620, Cisco 3640, and
•
Cisco 3725 routers; Cisco 4000 series routers; and the Cisco MC3810
multiservice concentrator support:
One-to-one cable for quasi-redundancy
–
Two-to-one Y-cable for full redundancy
–
Refer to the "Connecting Routers and the Cisco MC3810 Concentrator"
section on page 4-13
The Cisco RPS ships in either of the following configurations:
With cables (Cisco RPS number PWR600-AC-RPS-CAB)—Includes four
•
one-to-one (22-pin to 18-pin) cables for connecting to hubs and switches or
for quasi-redundant support for Cisco 2600 series routers; Cisco 3620,
Cisco 3640, and Cisco 3725 routers; and Cisco 4000 series routers.
Without cables (Cisco RPS number PWR600-AC-RPS-NCAB)—Cables
•
must be ordered separately:
One-to-one (22-pin to 18-pin) cables for connecting to hubs and switches
–
or for quasi-redundant support for Cisco 2600 series routers; Cisco 3620,
Cisco 3640, and Cisco 3725 routers; and Cisco 4000 series routers
– One-to-one (22-pin to 8-pin) cables for quasi-redundant support for
Cisco 2500 series routers and Cisco MC3810 multiservice concentrators
– Two-to-one Y cables (22-pin to 18-pin, or 22-pin to 8-pin) for fully
redundant support for routers or concentrators only
The fully redundant configuration is supported only for routers, not
Note
for hubs or switches.
Figure 3-1 and Figure 3-2
cable descriptions and lists the corresponding product order numbers. For
ordering information, contact 800 553-6387, 408 526-7208, or
cs-rep@cisco.com. See also the
page xviii.
Cisco Redundant Power System Hardware Installation Guide
for illustrations and procedures.
show the cables you can order, and
"Obtaining Documentation" section on
Ordering Cables
Table 3-1 includes
3-3
