Connecting Switches
Figure 4-8 Catalyst 2912 XL, Catalyst 2924 XL, and Catalyst 2924C XL Switch Rear Panel
RATING
100-127/ 200-240V~
1.0A/O.5 A 50-80HZ
AC power
connector
Figure 4-9 Catalyst 2912M XL and Catalyst 2924M XL Switch Rear Panel
CONSOL E
Cisco Redundant Power System Hardware Installation Guide
4-8
DC INPUTS FOR REMOTE
POWER SUPPLY
SPECIFI ED IN MANUAL
+5V @9A, +12V
@0.5A
CONSOL E
Cisco RPS
connector
DC INPUTS FOR REMOTE
POWER SUPPLY
SPECIFI ED IN MANUAL .
+5V @24A, +12V
@1.0A
DC INPUT
Cisco RPS
connector
Chapter 4 Connecting the Cisco RPS
RATING
~
100-120/ 200-240V
2.0A/1.0A 50-60HZ
AC power
connector
