Connecting Hubs

Warning
Warning
Warning
Warning
Connecting Hubs
Cisco Redundant Power System Hardware Installation Guide
4-2
Attach only the Cisco RPS (model PWR600-AC-RPS) to the RPS receptacle. To
see translations of the warnings that appear in this publication, refer to the
Regulatory Compliance and Safety Information document that accompanied this
device.
Before performing any of the following procedures, ensure that power is
removed from the DC circuit. To ensure that all power is OFF, locate the circuit
breaker on the panel board that services the DC circuit, switch the circuit
breaker to the OFF position, and tape the switch handle of the circuit breaker in
the OFF position. To see translations of the warnings that appear in this
publication, refer to the Regulatory Compliance and Safety Information
document that accompanied this device.
Before working on a system that has an on/off switch, turn OFF the power and
unplug the power cord. To see translations of the warnings that appear in this
publication, refer to the Regulatory Compliance and Safety Information
document that accompanied this device.
This unit might have more than one power cord. To reduce the risk of electric
shock, disconnect the two power supply cords before servicing the unit. To see
translations of the warnings that appear in this publication, refer to the
Regulatory Compliance and Safety Information document that accompanied this
device.
This section provides illustrations and cabling information for connecting the
Cisco RPS to the following hubs:
• Cisco 1516M hub (HP 10BASE-T Hub-16M)
• FastHub 400 series hubs
Chapter 4
(Figure
(Figure 4-2)
Connecting the Cisco RPS
4-1)
