Assembly 3: Electronics 2
Asm-index P/N Units/mach Units/FRU Description
1 40X8048
2 40X8266
3 40X8046
4 40X7795
4 40X7796
5 40X8047
6 40X8043
1 1 Front door sensor
1 1 Toner cartridge smart chip
contact
1 1 Toner density sensor
1 1 Power supply, 100 V/110 V
1 1 Power supply, 220 V
1 1 Trailing edge sensor
1 1 Duplex sensor and input
sensor
Parts catalog
Removal procedure
"Front door sensor removal" on page 211
"Toner cartridge smart chip contact
removal" on page 188
"Toner density sensor removal" on page
221
"Power supply removal" on page 216
"Power supply removal" on page 216
"Trailing edge sensor removal" on page
222
"Duplex sensor and input sensor removal"
on page 219
