Product Specification
General
Supply Voltage Range............................................................................................................... 18 − 40 V DC
Current Consumption (Max., all LEDs on)........................................................... 250 mA @ 24 V DC supply
Audio Output................................................................................................0 dBu balanced (nominal) / 66 Ω
Microphone Control Data.........................................................................................EIA RS485 / 19200 baud
Listen-in Audio................................................................................................... –10 dBu balanced (nominal)
Buttons......................................................................................................................20 Zone Select Buttons
LEDs ........................................................... 2 LEDs per zone Select button (zone Busy and zone Selected)
Microphone speech level meter ....................................................................................... Five LED bargraph
Colour .................................................................................................................. black with silver annotation
Format ............................................................................................................................... metal box console
Mounting .....................................................................................................................DIN 19" flush mounting
Dimensions and Weight
Dimensions (H x W x D) .................................................................................87.5 mm x 483 mm x 177 mm
Weight........................................................................................................................................... 3.9 kg max.
Variants
Standard Emergency Microphone (BS5839 Pt.8 compliant)
SMC02G (standard) ............................................................................................ Gooseneck microphone
SMC02F (standard)..........................................................................................................Fist microphone
Non-Emergency Microphone
SMC02GS ........................................................................................................... Gooseneck microphone
SMC02FS .........................................................................................................................Fist microphone
Environmental
Temperature (Storage and Operating) .................................................................................. −5 °C to +50 °C
Humidity Range ..................................................................................................0% to 93% Non-condensing
Ingress Protection.................................................................................................................................... IP55
1
Zone select buttons can also control routes or DVAs.
2
Functional only on standard SMC02 units, i.e, emergency microphones.
SMC02G/SMC02F/Variants - Product Manual
Issue: 02 complete, approved
Page 51 of 60
PTT button on console (SMC02G)
PTT button on fist microphone (SMC02F)
All Call Only (twin)
Speak Now (twin)
(excluding gooseneck microphone)
1
Listen-in button
2
Listen-in
System fault
Power
