5.6.2

Zone Selection Button

Menu: Configuration System Router Inputs Mic/Line <I/P #nn – MIC/LINE nn>
The Microphone Routing button function is for zone selection, i.e. when pressed it selects a specified output
or group of outputs to which the microphone audio is to be routed when the PTT button is subsequently
pressed.
See button operation in Sections
Messages (Play DVA Buttons)" (page 14).
If a 'listen-in' button has been configured, and it is activated while pressing a zone selection button, then the
selected output or group of outputs will be routed to the Router's Aux Output.
See button operation in Section
Configure a button for 'MIC Routing', and then select the output or group of outputs to which audio
(microphone) is to be routed when the Zone Select button is pressed.
Consult the system design documentation for which outputs are used for which audio zones. Note that to
simplify this process the Router may have had the output names changed to zone names in the
Configuration System Router Outputs menu.
5.6.3

DVA Routing Button (VAR4/VAR12/VAR20 only)

Menu: Configuration System Router Inputs Mic/Line <I/P #nn – MIC/LINE nn>
The 'DVA Routing' button function enables simple control of a single broadcast route, or complex broadcasts
to be set up. For instance when a button is pressed a route can be made that connects any desired
combination of audio inputs to any combination of outputs. Audio inputs are typically DVAs, however other
types of inputs such as microphone and background music can also be routed.
An example of this is a button programmed to cause an EVACUATE message to be broadcast in one zone,
and simultaneously cause an ALERT message to be broadcast to adjacent zones, while all remaining zones
are unaffected.
Another example would be a set of 'DVA Routing' buttons which controls background music broadcast to
selected zones in the system.
DVA Routing is only available on microphones connected to VAR4/VAR12/VAR20's Mic/Line
!
!
inputs 1 or 2.
See button operation in Section
Configure a button for 'DVA Routing', and then configure the following parameters.
SMC02G/SMC02F/Variants - Product Manual
<Zoned Fire Microphone or Paging Microphone> Buttons <Button # nn>
"2.2.1 Live Announcements" (page 9), and
"2.2.4.2 Selective Listen-In
<Zoned Fire Microphone or Paging Microphone> Buttons <Button # nn>
"2.2.2 Routing Digital Voice Messages (DVA Routing
Issue: 02 complete, approved
Page 37 of 60
"2.2.3 Playing Digital Voice
Mode" (page 18).
MIC Routing
DVA Routing
Buttons)" (page 12).
