5.4
Configuring the PTT Button (VAR4/VAR12/VAR20 only)
5.4.1.1
PTT Button Cough Timeout (VAR4/VAR12/VAR20 only)
Menu: Configuration System Router Inputs Mic/Line <I/P #nn – MIC/LINE nn>
Possible values:
System default configuration: '0'
The cough timeout is the time length the PTT button may be released before the route is closed down. The
audio path is muted immediately when the PTT button is released, allowing the operator to cough without it
being broadcast. If the PTT button is re-pressed within the coughing time, the announcement will continue as
normal.
5.4.1.2
PTT All Call Mode (VAR4/VAR12/VAR20 only)
Menu: Configuration System Router Inputs Mic/Line <I/P #nn – MIC/LINE nn>
Possible values:
System default configuration: 'AllCall Disabled'
The PTT button may be configured just to act as a Push To Talk on zones selected by other buttons, or it
may be configured so that when pressed without a prior zone selection then it acts as an All-Call button
functioning as 'select all zones' available from this microphone. If configured to the latter mode, when the
button is pressed with no zone selection button pressed the announcement will be routed to all outputs,
which have been configured to any zone selection button on that microphone, i.e. the button press has the
same effect as if all zone selection buttons on the microphone have been pre-selected. Subsequently
pressing a zone selection button will remove the zones associated to this button from the All-Call selection.
5.4.1.3
PTT Restore Mode (VAR4/VAR12/VAR20 only)
Menu: Configuration System Router Inputs Mic/Line <I/P #nn – MIC/LINE nn>
Possible values:
System default configuration: 'Restore Disabled'
The PTT button may be configured to store the last zones selected for paging, and to automatically re-page
the same zones when pressed again with no zone buttons selected.
SMC02G/SMC02F/Variants - Product Manual
<Zoned Fire Microphone or Paging Microphone> Buttons Cough
00 to 50 (Time in tenths of a second. Divide by ten for the time in seconds.)
<Zoned Fire Microphone or Paging Microphone> PTT
'AllCall Disabled' or 'AllCall Enabled'
<Zoned Fire Microphone or Paging Microphone> PTT
'Restore Disabled' or 'Restore Enabled'
Issue: 02 complete, approved
Page 35 of 60
AllCall Disabled or AllCall Enabled
Restore Disabled or Restore Enabled
