Installation

3.1

Installation Requirements

3.1.1

Equipment and Tool Requirements

•
The SMC02 unit.
•
SMC02 connection cable: ASL SMCLEAD-5M, SMCLEAD-20M, or parts to assembly such a cable.
•
Suitable marshalling box for connecting the site wiring to the SMC02 connection cable.
•
Zone identification labels.
A template for printing these labels is available from the "Data Downloads" page of Application Solutions
website: www.asl-electronics.co.uk/downloads.
•
PC and printer for completing, and printing the zone identification labels.
•
A 2 mm Allen key or driver.
•
A large pozidrive screwdriver.
•
Suitable wire cutters, strippers and crimp tools (ITT Cannon 112108-0014 or R.S. 450-4411).
•
Suitable fixings for mounting the fist microphone clip (SMC02F and SMC02FS only).
3.1.2

Cabling Requirements

3.1.2.1

From Rack to Marshalling Box within Control Room

•
Standard SMC02 Units (SMC02G/SMC02F):
Signals
Microphone Audio
Listen-In Audio
Microphone Data
Other Signals
•
'S' Variant Paging Microphone SMC02 Units (SMC02GS/SMC02FS):
Signals
Microphone Audio
Listen-In Audio
Microphone Data
Other Signals
For cable-run limitations and alternative cable types please refer to Application Solutions
Limited for advice.
For EMC compliance:
! !
• All cable tails must be <3 cm.
•
Screened cables to be used where specified.
SMC02G/SMC02F/Variants - Product Manual
Cable Description
1 x 2 core, twisted, screened. 1.0 mm
1 x 2 core, twisted, screened. 1.0 mm
1 x 2 core, twisted, screened. 1.0 mm
1 x 7 core, screened 1.0 mm
Cable Description
1 x 2 core, twisted, screened. 1.0 mm
1 x 2 core, twisted, screened. 1.0 mm
1 x 2 core, twisted, screened. 1.0 mm
1 x 7 core, screened 1.0 mm
Issue: 02 complete, approved
Fire Rated. MICC, Pirelli FP200 or equivalent
Fire Rated. MICC, Pirelli FP200 or equivalent
Fire Rated. MICC, Pirelli FP200 or equivalent
Fire Rated. MICC, Pirelli FP200 or equivalent
CAT 5 STP
CAT 5 STP
CAT 5 STP
CAT 5 STP
Page 19 of 60
Suggested Type
Suggested Type
