5.6.5

Play DVA Button (ACU only)

Menu: Configuration System Router Inputs Mic/Line <I/P #nn – MIC/LINE nn>
<Zoned Fire Microphone or Paging Microphone> Buttons <Button # nn> Play DVA
The button function is 'play DVA to selected outputs'. When the button is pressed a route is made connecting
a DVA audio source from the Slave Unit or the Audio Control Unit (ACU) to outputs which have been pre-
selected using buttons configured for zone selection.
The 'Play DVA' button can be considered a variant of the 'DVA Routing' button, which routes only one DVA
audio source, and requires the zones to be pre-selected using Zone Select buttons.
See button operation in Section
Configure a button for 'Play DVA', and then configure the following parameters.
5.6.5.1

DVA Message

Menu: Configuration System Router Inputs Mic/Line <I/P #nn – MIC/LINE nn>
The DVA source can be from the:
•
Audio Control Unit (ACU):
The ACU's DVA will be played over the network to selected zones.
•
Slave Unit in the Intellevac Network:
The local DVA will be played to selected zones.
It is necessary to select the DVA audio source which will be played to the selected zones.
Consult the system design documentation for which DVA input is under the control of this button.
5.6.5.2

Trigger Mode

Menu: Configuration System Router Inputs Mic/Line <I/P #nn – MIC/LINE nn>
System default configuration: 'Not Latched'
It is possible to configure how the route will be triggered:
•
'Not Latched' mode
The first press of a 'DVA Routing' button initiates a route, and a second press terminates it.
Example is for non-emergency DVA broadcast.
•
'Latched' mode
This mode needs a reset button. Pressing a 'Play DVA' button initiates a route; and pressing the
associated reset button terminates it.
Example is for emergency DVA broadcast.
Program the reset button specified in the system design documentation via the following menu option.
Menu: Configuration System Router Inputs Mic/Line <I/P #nn – MIC/LINE nn>
SMC02G/SMC02F/Variants - Product Manual
"2.2.3 Playing Digital Voice Messages (Play DVA
<Zoned Fire Microphone or Paging Microphone> Buttons <Button # nn>
NETWORK IP
SLAVE IP
<Zoned Fire Microphone or Paging Microphone> Buttons <Button # nn>
<Zoned Fire Microphone or Paging Microphone> Buttons <Button # nn>
Issue: 02 complete, approved
Page 40 of 60
Buttons)" (page 14).
Play DVA Select DVA
Play DVA Control Latching Mode
Play DVA Control Latching ResetButton
