5.3.3

Microphone Name

Menu: Configuration System Router Inputs Mic/Line <I/P #nn – MIC/LINE nn>
Possible values:
System default configuration: 'MIC/LINE nn', where nn is the input number
The Router associates a default name with the microphone input, which is 'MIC/LINE nn' (where nn is the
Router's input number).
This name is for reference only in the Router settings, and may be modified as required.
5.3.4

Microphone Protocol (ACU only)

Menu: Configuration System Router Inputs Mic/Line <I/P #nn – MIC/LINE nn>
<Zoned Fire Microphone or Paging Microphone> Ctrl Protocol Paging mic protocol
Possible values:
System default configuration: 'Console mic protocol' on Zone Fired Microphones
The ACU (Audio Control Unit) requires the protocol used for communication with the microphone connected
to a Mic/Line input to be defined. Normally the 'Paging mic protocol' is used for communication with ASL
microphones, being the 'Console mic protocol' used with the ACU's built-in microphone.
Ensure that the Mic/Line input used by the SMC02 is configured for 'Paging mic protocol'.
5.3.5

Microphone Button Capacity (ACU only)

Menu: Configuration System Router Inputs Mic/Line <I/P #nn – MIC/LINE nn>
Possible values:
System default configuration: '100 Button' on Zone Fired Microphones
Program the Mic/Line input used by the SMC02 to support the required number of buttons ('20 Button').
SMC02G/SMC02F/Variants - Product Manual
<Zoned Fire Microphone or Paging Microphone> Name
alphanumeric string of up to 12 characters
'Console mic protocol' or 'Paging mic protocol'
'Paging mic protocol' on Paging Microphones
<Zoned Fire Microphone or Paging Microphone> Ctrl Capacity 20 Button
5, 10, 20, 40, 60, 80, 100 buttons
'10 Button' on Paging Microphones
Issue: 02 complete, approved
Page 33 of 60
