ASL INTERCOM SMC02G Product Manual page 11

SPEAK NOW
ON
SMC02G SMC02F
OK
SPEECH LEVEL
LOUDSPEAKER
ANNOUNCEMENT IN PROGRESS
PRESS TO TALK BUTTON
SMC02G
OR
PTT
RELEASE
SMC02G/SMC02F/Variants - Product Manual
6.
When the chime has finished (if programmed at the
Router), the SPEAK NOW LED will illuminate. If no
chime has been programmed then the SPEAK NOW
LED will illuminate immediately.
Once the SPEAK NOW LED has illuminated you can
make the announcement.
Recommendations for Optimum Results
Speak slowly and clearly while observing the correct
positioning of the microphone in relation to your mouth:
a. Gooseneck microphone:
b. Fist microphone:
The SPEECH LEVEL meter indicates the sound pressure
being received at the microphone, and is annotated to
indicate the correct speaking level.
7.
When finished release the PTT button. Once the PTT
SMC02F
button is released the system automatically resets ready
for the next announcement.
Issue: 02 complete, approved
Page 11 of 60
Speak at a normal conversational level positioning
the mouth 5-10 cm from the microphone capsule.
Speak at a normal conversational level with the
mouth directly adjacent to the Fist Microphone
capsule. A lip-guard is fitted to the front of the Fist
Microphone, which should be placed directly above
the top lip.
On VAR4/12/20 a 'cough timeout' is configurable. If
the 'cough timeout' has been configured at the
Router, then the PTT button can be released to
stop the broadcast while the user coughs, and then
re-pressed to continue the broadcast. The PTT
button must be re-pressed within the configured
cough timeout, or the broadcast will be ended.
If a higher priority input selects a zone during a
paging announcement from the SMC02, then the
zone will be deselected from the SMC02 and the
SELECT LED will go out. The announcement will
continue to any other zones if the SMC02
addresses a group of zones.
