5.6.3.3

DVA Play Mode

Menu: Configuration System Router Inputs Mic/Line <I/P #nn – MIC/LINE nn>
Possible values:
System default configuration: 'DVA-Full'
If the DVA is configured to 'Play Once', then this setting should be 'DVA-Full'.
The DVA play mode is only relevant for routing DVAs.
The DVA assigned to a 'DVA Routing' button may be configured to cease playing when the route is
terminated or reset ('DVA-Part'), or play until its end ('DVA-Full').
5.6.3.4

Busy Indication Mode

Menu: Configuration System Router Inputs Mic/Line <I/P #nn – MIC/LINE nn>
Possible values:
System default configuration: 'Busy=On'
It is possible to configure whether or not the route associated with a 'DVA Routing' button should cause a
busy indication on the LEDs associated with microphone zone select buttons. If for instance this routing were
used for background music control, then the busy LEDs would not need to be lit. If another type of route
were being made, then the busy LEDs would normally be lit.
5.6.4

All Call Button

Menu: Configuration System Router Inputs Mic/Line <I/P #nn – MIC/LINE nn>
The button function is 'select all zones'. When the button is pressed, all outputs, which have been configured
as being affected by any zone selection buttons on the microphone, are selected for broadcast from the
microphone, i.e. the button press has the same effect as if all zone selection buttons on the microphone
have been pressed. Pressing a zone selection button will remove the zones associated to this button from
the selection. Any button may be configured as an All-Call button.
See button operation in Section
SMC02G/SMC02F/Variants - Product Manual
<Zoned Fire Microphone or Paging Microphone> Buttons <Button # nn>
'DVA-Full', 'DVA-Part'
<Zoned Fire Microphone or Paging Microphone> Buttons <Button # nn>
'Busy=On', 'Busy=Off'
<Zoned Fire or Paging Microphone> Buttons <Button # nn> AllCall
"2.2.1 Live Announcements" (page 9).
Issue: 02 complete, approved
Page 39 of 60
DVA Routing Control DVA-Full or DVA-Part
DVA Routing Control Busy=On or Off
