'Play Once' mode
Pressing a 'Play DVA' button plays the DVA associated with the route once only. When the DVA has
completed its full message cycle, the route is terminated.
Example is for a 'Mind the Gap' broadcast.
5.6.5.3

DVA Play Mode

Menu: Configuration System Router Inputs Mic/Line <I/P #nn – MIC/LINE nn>
Possible values:
System default configuration: 'DVA-Full'
If the DVA is configured to 'Play Once', then this setting should be 'DVA-Full'.
The DVA assigned to a 'Play DVA' button may be configured to cease playing when the route is terminated
or reset ('DVA-Part'), or play until its end ('DVA-Full').
5.6.5.4

Busy Indication Mode

Menu: Configuration System Router Inputs Mic/Line <I/P #nn – MIC/LINE nn>
Possible values:
System default configuration: 'Busy=On'
It is possible to configure whether or not the route associated with a 'Play DVA' button should cause a busy
indication on the LEDs associated with microphone zone select buttons. If for instance this routing were used
for background music control, then the busy LEDs would not need to be lit. If another type of route were
being made, then the busy LEDs would normally be lit.
5.6.6

Cancel All DVAs Button (ACU only)

Menu: Configuration System Router Inputs Mic/Line <I/P #nn – MIC/LINE nn>
The button function is 'stop all DVAs'. Pressing the button stops DVAs playing to any zone. The
announcement will stop playing immediately, or play until its end depending on how the DVA is configured.
Note that contact DVAs, i.e., activated by Fire Panel, are not affected by the activation of this button.
See button operation in Section
SMC02G/SMC02F/Variants - Product Manual
<Zoned Fire Microphone or Paging Microphone> Buttons <Button # nn>
'DVA-Full', 'DVA-Part'
<Zoned Fire Microphone or Paging Microphone> Buttons <Button # nn>
'Busy=On', 'Busy=Off'
<Zoned Fire Microphone or Paging Microphone> Buttons <Button # nn>
"2.2.3 Playing Digital Voice Messages (Play DVA
Issue: 02 complete, approved
Page 41 of 60
Play DVA Control DVA-Full or DVA-Part
Play DVA Control Busy=On or Off
Buttons)" (page 14).
Cancel-All-DVAs
