2.2.4.2

Selective Listen-In Mode

In Selective Listen-in mode the audio of selected zones are mixed and fed to the listen-in speakers on all off
SMC units controlled by the Router.
OFF
PA LISTEN
PA
LISTEN
BUTTON
PRESS AND HOLD
PA LISTEN
PA
LISTEN
BUTTON
ZONE
SELECT
BUTTON
VOLUME PA LISTEN
- +
PA LISTEN
PA
LISTEN
BUTTON
SMC02G/SMC02F/Variants - Product Manual
1.
ZONE
SELECT
BUTTON
2.
ON
3.
ON
4.
PA
LISTEN
BUTTON
OFF
5.
Issue: 02 complete, approved
Activate the selective listen-in function by holding down
the PA LISTEN button and pressing the required Zone
Select button on the primary SMC02 unit.
Listen-in is not possible while the SMC02 is used
for announcements.
This will cause only the audio of the selected zone (or
group of zones) to be fed to the listen-in speaker.
The PA LISTEN LED illuminates to indicate that the
listen-in function is activated.
Normal paging is not possible while the listen-in
function is activated.
Add the audio from other zones to the mix by pressing
other Zone Select buttons.
De-select zones by re-pressing the Zone Select buttons.
Adjust the audio mix volume using the PA LISTEN
VOLUME switch.
Deactivate the listen-in function by re-pressing the
PA LISTEN switch.
The PA LISTEN LED will extinguish to show that the
listen-in mode has been deactivated. Announcements
can now be made.
