5.5

Configuring the Listen-in Button

5.5.1.1

Listen-in Button

Menu: Configuration System Router Inputs Mic/Line <I/P #nn – MIC/LINE nn>
Possible values:
System default configuration: 'Not-Conf'
See Listen-in button operation in Section
Program switch '4' for 'Listen-in' in order to enable the listen-in function on the PA LISTEN button on the
SMC02 console.
5.6

Configuring the Microphone Buttons

Buttons on Paging Microphone or a Zoned Fire Microphone may be configured as either:
•
Not-Conf
•
MIC Routing
•
DVA Routing (VAR4/VA12/VAR20 only)
'DVA Routing' is only available on Paging or Zoned Fire Microphones that are connected to
!
!
VAR4/VA12/VAR20's Mic/Line inputs 1 or 2.
•
All-Call
•
Route Reset
•
Play DVA (ACU only)
•
Cancel All DVAs (ACU only)
Each of these configurations is described in the following sections.
Consult the system design documentation to find the configuration of each button on the SMC02.
5.6.1

Unused Buttons

Menu: Configuration System Router Inputs Mic/Line <I/P #nn – MIC/LINE nn>
Any button that is not in use should be configured as unused, to prevent inadvertent operation.
SMC02G/SMC02F/Variants - Product Manual
<Zoned Fire or Paging Microphone> Buttons <Button # nn>
'Not-Conf', 'Listen-in', or 'Security' (not used for SMC02)
"2.2.4 Listen-in
<Zoned Fire Microphone or Paging Microphone> Buttons <Button # nn>
Issue: 02 complete, approved
Page 36 of 60
Switches Switch #4 Listen-in
Operation" (page 17).
Not-Conf
