5.7.6
Microphone Pre-Annoucement Chime
Menu: Configuration System Router Inputs Mic/Line <I/P #nn – MIC/LINE nn>
Possible chime level:
Possible chime types:
System default configuration: 'Type=Off' and 'LEVEL (dB) –12'
A pre-announcement chime may be configured to any Mic/Line input. If configured, then the chime will be
triggered when the input source is routed. However the actual audio input will only be routed when the chime
is complete. The chime level is also configurable.
SMC02G/SMC02F/Variants - Product Manual
<Zoned Fire Microphone or Paging Microphone> Audio Chime
–40dB to 0dB (1dB steps)
'Chime-1' (one chime)
'Chime-2': two chimes
'Chime-3': three chimes
'Off': none
Issue: 02 complete, approved
Page 46 of 60
