Draytek Vigor2130 Series User Manual page 77

WAN IP Network Settings You can choose Static IP or DHCP as WAN IP network setting.
IP Address
Subnet Mask
Primary DNS Server
Secondary DNS Server
Redial Policy
Idle Time Out
MTU Size
Fixed IP (IPCP)
Fixed IP Address (IPCP)
Clone MAC Address
After finishing all the settings here, please click OK to activate them.
Vigor2130 Series User's Guide
Type the IP address if you choose Static IP as the WAN IP
network setting.
Type the subnet mask if you chose Static IP as the WAN IP.
You must specify a DNS server IP address here because your
ISP should provide you with usually more than one DNS Server.
If your ISP does not provide it, the router will automatically
apply default DNS Server IP address: 194.109.6.66 to this field.
You can specify secondary DNS server IP address here because
your ISP often provides you more than one DNS Server. If your
ISP does not provide it, the router will automatically apply
default secondary DNS Server IP address: 194.98.0.1 to this
field.
If you want to connect to Internet all the time, you can choose
Always On. Otherwise, choose Connect on Demand and
Set the timeout for breaking down the Internet after passing
through the time without any action. When you choose Connect
on Demand, you have to type value here.
It means Max Transmit Unit for packet. The default setting will
be specified by the system automatically. Therefore, keep this
field in blank.
Usually ISP dynamically assigns IP address to you each time
you connect to it and request. In some case, your ISP provides
service to always assign you the same IP address whenever you
request. In this case, you can fill in this IP address in the Fixed
IP field. Please contact your ISP before you want to use this
function. Click Yes to use this function
Type in a fixed IP address in the box if you click Yes for Fixed
IP(IPCP).
It is available when the box of Enable is checked. Click Clone
MAC Address. The result will be displayed in the field of
MAC Address.
69
