External Locator - Front & Left Side Views
Figure 3
Front View
1. LCD Latches
2. Mini IEEE 1394
Port
3. S/P DIF Out Port
4. Microphone Jack
5. Headphone Jack
6. Infrared
Transceiver
7. Wireless Device
ON/OFF Switch
8. Built-In Speakers
Figure 4
Left Side View
1. 6-in1 Card Reader
2. CD-ROM Bezel or
CD-ROM Device
3. PC Card/ PCMCIA
Slot
4. PC Card/PCMCIA
Slot Eject Buttons
