Removing the Keyboard Shielding Plate

1. Turn off the computer, remove the battery (
2. Remove screws - from the keyboard shielding plate and lift the plate
1 9
a.
1 2 3 4
6
8
page 2 - 8
) and keyboard (
b.
5
7
9
page 2 - 18
).
off the computer.
10
10
Removing the Keyboard Shielding Plate 2 - 19
Disassembly
Figure 12
Keyboard Shielding
Plate Removal
a. Remove the screws from
the shielding plate.
b. Lift the shielding plate off
the computer.
10. Shielding Plate
• 9 Screws
