EUROCOM D400V Service Manual page 39

4. Use a screwdriver to carefully push the CD device assembly
2
5. Insert the new device and carefully slide it into the computer (the device only fits one way. DO NOT FORCE IT; The
screw holes should line up.
6. Replace the memory socket cover (be careful with the fan cable) and the 6 screws (see
7. Restart the computer to allow it to automatically detect the new device.
out of the computer at point
1 2
page 2 - 12
Disassembly
.
Figure 6
CD Device Removal
Push the CD device out
off the computer at point
2.
1
).
1. CD Device
Removing the CD Device 2 - 13
